Cub Cadet 528 SWE Illustrated Parts List

Ref.
Part Number Description
1. 710-1652 AB Screw, 1/4-20 x 0.625
2. 731-05353 Belt Cover
3. 732-0705 Cable Guide
4. 711-1268B Actuator Shaft
5. 746-04229 Drive Clutch Cable
6. 732-04345 Extension Spring
7. 790-00207A Drive Clutch Cable Guide Bracket
8. 684-04156A Shift Rod Assembly
9. 750-04474 Axle Support Tube
10. 714-0126 Hi-pro Key
11. 710-04022 Screw
12. 717-04210 Gear, 56T
13. 741-0245 Hex Flange Bearing
14. 790-00206A Auger Clutch Cable Guide Bracket
15. 756-0625 Cable Roller
16. 738-0924A C Screw, 1/4-28 x 0.375
17. 618-04288 Dogg Assembly - LH
— 618-04287 Dogg Assembly - RH
18. 726-04012 Speed nut
19. 750-04477 Spacer
20. 736-00156 Shift Bracket Spacer
21. 732-04311 Torsion Spring, .750ID x .968 Lg.
22. 731-05297 Spacer
23. 716-0104 E Ring
24. 736-0188 Flat Washer, .76 x 1.49 x .06
25. 736-0626 Flat Washer
26. 741-04076 Ball Bearing
27. 738-04180 Axle
28. 731-04873 Spacer
29. 710-0654A TT Sems Screw, 3/8-16 x 1.0
30. 710-0788 TT Screw, 1/4-20 x 1.0
31. 790-00185 Shaft Retainer - LH
32. 634-04136 Wheel Complete - LH (16x6.5x8)
— 634-04137 Wheel Complete - RH (16x6.5x8)
— 634-04147A Wheel Complete - LH (15x5x6)
— 634-04148A Wheel Complete - RH (15x5x6)
33. 736-0242 Bell Washer
34. 710-0627 Hex Bolt, 5/16-24 x 0.75
35. 684-04154 Friction Wheel Support Brkt. Assy.
36. 790-00096 Auger Cable Guide Bracket
37. 748-0190 Spacer
38. 738-04184A Shoulder Screw
39. 790-00316 Frame Cover
Ref.
Part Number Description
40. 656-04025A Friction Wheel Disc Assembly
41. 618-04322A Drive Shaft Assembly
42. 684-04159 Friction Wheel Assembly
43. 716-0136 Retainer Ring
44. 726-0221 Speed Nut
45. 790-00183B Wheel Drive Frame
46. 756-04109 Auger Pulley
47. 736-0505 Flat Washer
48. 710-1245B Hex Bolt, 5/16-24 x 0.875
49. 736-0119 Lock Washer
50. 684-04169 Pulley Assembly
51. 748-0234 Shoulder Spacer
52. 750-04571 Spacer
53. 732-04308A Torsion Spring
54. 710-0672 Hex Screw, 5/16-24 x 1.25
55. 756-04252 Pulley Half
56. 754-0367 V-Belt, ⁄ x 34
57. 710-0809 TT Screw, 1/4-20 x 1.25
58. 790-00208B Drive Clutch Idler Bracket
59. 748-04112A Shoulder Spacer
60. 732-0264 Extension Spring
61. 712-0413 Jam Lock Nut, 5/8-18
62. 750-04303 Spacer
63. 756-04113 Pulley Half
64. 736-0247 Flat Washer
65. 710-0191 Hex Bolt, 3/8-24 x 1.25
66. 748-04053A Pulley Adapter
67. 746-0956A Steering Cable
68. 790-00186 Shaft Retainer - RH
69. 750-0767 Axle Spacer
70. 712-04065 Flange Lock Nut, 3/8-16
71. 754-04050 V-Belt,.500 x 35.00 Lg
72. 710-0751 Hex Screw, 1/4-20 x .620
73. 790-00217A Speed Selector Pivot Bracket
74. 790-00218A Speed Selector Shift Bracket
75. 712-04063 Flange Lock Nut, 5/16-18
76. 712-04064 Flange Lock Nut, 1/4-20
77. 618-0063A Friction Wheel Bearing Assembly
78. 718-04144 Friction Wheel Hub
79. 790-00174 Friction Wheel Plate
80. 735-04054 Friction Wheel Rubber
81. 710-0896 AB Screw
82.
790-00298A Cover Plate
5
Drive System

Cub Cadet 528 SWE Specifications

General

Engine Type	4-cycle OHV
Engine Displacement	277cc
Clearing Width	28 inches
Intake Height	21 inches
Auger Diameter	12 inches
Speeds	6 forward / 2 reverse
Stages	Two-stage
Auger Material	Steel
Impeller Diameter	12 inches
Start Type	Recoil
Throw Distance	40 ft
Starter	Electric
Fuel Tank Capacity	5 qt
Skid Shoes	Adjustable
Warranty	3-year limited
Chute Rotation	200°
