Cub Cadet 528 SWE Illustrated Parts List

Ref.
Part Number Description
1. 684-04106B Handle Engagement Assembly RH
2. 738-04194 Flange Shoulder Screw
3. 731-04894C Lock Plate
4. 711-04250 Pivot Rod
5. 735-0199A Rubber Bumper
6. 710-04354 Screw, 1/4-20 x.375
7. 731-04896B Clutch Lock Cam
8. 712-04081A Shoulder Nut, 1/4-20
9. 725-04314 Wire Harness (Not Shown)
10. 725-1649 Light Socket
11. 720-0274 Handle Grip
12. 710-1233 Screw, #10-24 x 0.375
13. 738-04122 Shoulder Screw, 1/4-20 x 1.345
14. 710-04586 Screw, 1/4-20 x 1.625
15. 749-04190A Upper Handle RH
16. 710-0449 Carriage Screw, 5/16-18 x 2.25
17. 720-04039 Shift Knob
18. 631-04187 Handle Panel (Includes Ref. #19)
19. 731-05324 Lens
20. 725-1649 Lamp
21. 631-04134B Handle Clutch Lock RH Assy
22. 725-0157 Cable Tie
23. 712-04064 Flange Lock Nut, 1/4-20
24. 732-0193 Compression Spring
25. 790-00203 Shift Lever
26. 790-00248 Panel Bracket
27. 738-04125 Shoulder Screw
28. 746-04396 Speed Selector Cable
29. 736-0463 Flat Washer, .25 x .630 x .0515
30. 710-0606 Hex Screw, 1/4-20 x 1.50
Ref.
Part Number Description
31. 731-04427A Upper Chute
32. 790-00155 Joystick Bracket
33. 710-04187 Hi-Lo Screw, 1/4-15 x 0.5
34. 684-04116B 4-Way Chute Control™ Assembly
35. 749-04191A Upper Handle LH
36. 710-04326 Screw, #8-16 x 0.50
37. 732-04219A Clutch Lock Spring
38 731-04954 Steering Control
39. 738-04126 Pin, 3/16
40. 716-04036 E Ring
41. 631-04133 Handle Clutch Lock LH Assy
42. 684-04105B Handle Engagement Assembly LH
43. 784-5594 Cable Bracket
44. 720-0284 Wing Knob
45. 712-04063 Flange Lock Nut, 5/16-18
46. 731-1313C Chute Tilt Cable Guide
47. 711-04469A Clevis Pin
48. 710-04484 Hex Screw
49. 749-04138 Lower Handle
50. 732-04238 Torsion Spring
51. 736-0267 Flat Washer
52. 731-04890A Joystick Pulley Cover
53. 710-0262 Carriage Bolt, 5/16-18 x 1.50
54. 710-0895 Hi-Lo Screw, 1/4-15 x .75
55. 710-04071 Carriage Bolt, 5/16-18 x 1.0
56. 731-04861B Lower Chute
57. 710-0627 Hex Screw, 5/16-24 x .750
58. 684-04162B Chute Support Bracket
59. 712-3087 Wing Nut, 1/4-20
60. 714-04040 Bow Tie Cotter Pin
61. 726-0470 Cable Tie
7
T-Style Handle, Frame & Discharge Chute

Cub Cadet 528 SWE Specifications

General

Engine Type	4-cycle OHV
Engine Displacement	277cc
Clearing Width	28 inches
Intake Height	21 inches
Auger Diameter	12 inches
Speeds	6 forward / 2 reverse
Stages	Two-stage
Auger Material	Steel
Impeller Diameter	12 inches
Start Type	Recoil
Throw Distance	40 ft
Starter	Electric
Fuel Tank Capacity	5 qt
Skid Shoes	Adjustable
Warranty	3-year limited
Chute Rotation	200°
