Cub Cadet 528 SWE User Manual

25
9
Parts List
1. 684-04106A Handle Engagement Assembly RH
2. 747-04263 Eye Bolt
3. 731-04894A Lock Plate
4. 711-04287 Pivot Rod
5. 735-0199A Rubber Bumper
6. 710-04354 Screw, 1/4-20 x.375
7. 731-04896A Clutch Lock Cam
8. 712-04081A Shoulder Nut, 1/4-20
9. 725-04216A Wire Harness (Not Shown)
10. 725-1649 Light Socket
11. 720-0274 Handle Grip
12. 710-1233 Screw, #10-24 x 0.375
13. 738-04122 Shoulder Screw, 1/4-20 x 1.345
14. 710-1026 Screw, 1/4-20 x 1.750
15. 749-04190 Upper Handle RH
16. 710-0449 Carriage Screw, 5/16-18 x 2.25
17. 720-04039 Shift Knob
18. 631-04183 Handle Panel (Includes Ref. #19)
19. 731-05320 Lens
20. 725-04213 Lamp
21. 731-04784A Handle Clutch Lock - RH
22. 725-0157 Cable Tie
23. 712-04064 Flange Lock Nut, 1/4-20
24. 732-0193 Compression Spring
25. 790-00203 Shift Lever
26. 790-00140 Panel Bracket
27. 738-04125 Shoulder Screw
28. 746-0605 Cable Barrel Holder
29. 746-04227 Speed Selector Cable
30. 736-0463 Flat Washer, .25 x .630 x .0515
31. 710-0224 Screw, #10-16 x .500
32. 736-0185 Flat Washer, .375 x .738 x .063
33. 731-04427A Upper Chute
34. 714-0104 Cotter Pin
35. 710-04187 Hi-Lo Screw, 1/4-15 x 0.5
36. 684-04117 2-Way Chute Control™ Assembly
37. 749-04191 Upper Handle LH
38. 710-04326 Screw, #8-16 x 0.50
39. 732-04219 Clutch Lock Spring
40. 731-04954 Steering Control
41. 738-04126 Pin, 3/16
42. 716-04036 E Ring
43. 731-04785 Handle Clutch Lock - LH
44. 684-04110A Handle Engagement Assembly LH
45. 784-5594 Cable Bracket
46. 720-0284 Handle Knob Assembly
47. 736-0451 Saddle Washer
48. 712-04063 Flange Lock Nut, 5/16-18
49. 731-1313C Chute Tilt Cable Guide
50. 712-0161 Hex Lock Nut, #10-24
51. 726-0100 Push Cap
52. 710-0726 AB Screw, 5/16-12 x 0.75
53. 749-04138 Lower Handle
54. 726-0470 Cable Tie
55. 732-04238 Torsion Spring
56. 736-0262 Flat Washer
57. 735-0234 Rubber Grommet
58. 710-0262 Carriage Bolt, 5/16-18 x 1.50
59. 710-0895 Hi-Lo Screw, 1/4-15 x .75
60. 710-04071 Carriage Bolt, 5/16-18 x 1.0
61. 631-04131A Lower Chute Ass’y (Incl. Ref. #62)
731-04912A Lower Chute Only
62. 731-04869 Flange Keeper
63. 710-0267 Carriage Screw, 5/16-18 x 1.00
64. 736-0159 Flat Washer, .349 x .879 x .063
65. 720-0201A Chute Directional Control Knob
66. 741-0475 Plastic Bushing
67. 784-5647 Chute Directional Control Bracket
68. 684-04104 Chute Directional Control
To order replacement
parts, call the Customer
Dealer Referral Line at
1-877-282-8684,
or visit
www.cubcadet.com to
find the nearest Cub
Cadet service dealer in
your area.

Cub Cadet 528 SWE Specifications

General

Engine Type	4-cycle OHV
Engine Displacement	277cc
Clearing Width	28 inches
Intake Height	21 inches
Auger Diameter	12 inches
Speeds	6 forward / 2 reverse
Stages	Two-stage
Auger Material	Steel
Impeller Diameter	12 inches
Start Type	Recoil
Throw Distance	40 ft
Starter	Electric
Fuel Tank Capacity	5 qt
Skid Shoes	Adjustable
Warranty	3-year limited
Chute Rotation	200°
