Cub Cadet 528 SWE User Manual

23
9
Parts List
To order replacement
parts, call the Customer
Dealer Referral Line at
1-877-282-8684,
or visit
www.cubcadet.com to
find the nearest Cub
Cadet service dealer in
your area.
1. 731-2643 Clean-Out Tool
2. 712-04065 Flange Lock Nut
3. 756-0981A Flat Idler Pulley
4. 710-0347 Hex Bolt, 3/8-16 x 1.75
5. 790-00080 Auger Idler Bracket
6. 736-0174 Wave Washer
7. 738-0281 Shoulder Screw
8. 790-00181 Blade Guide
9. 738-0143 Shoulder Screw
10. 790-00075 Bearing Housing
11. 726-04012 Push Nut
12. 712-04063 Flange Lock Nut, 5/16-18
13. 741-0309 Ball Bearing
14. 732-0611 Extension Spring
15. 710-0604A AB Screw, 5/16-18 x 0.625
16. 731-04705 Chute Adapter
17. 710-0703 Carriage Screw, 1/4-20 x 0.75
18. 731-2635 Clean-out Tool Mtg. Bracket
19. 684-04073 Auger Housing Assembly: 28”
20. 712-04064 Flange Lock Nut, 1/4-20
21. 736-0463 Flat Washer
22. 618-04173 Gearbox Assembly Complete
23. 790-00141 Slide Shoe
24. 710-0451 Carriage Bolt
25. 790-00145 Shave Plate
26. 684-04057 Impeller Assembly
27. 717-04126 Worm Shaft
28. 721-0327 Oil Seal
29. 741-0662 Flange Bearing
30. 718-04071 Thrust Collar
31. 741-0663 Flange Bearing
32. 710-0642 TT Screw, 1/4-20 x 0.75
33. 790-00087A Bearing Housing
34. 721-0325 Plug
35. 736-3084 Flat Washer
36. 715-04021 Dowel Pin
37. 684-04108 Spiral Assembly- RH
38. 618-0123 Reducer Hsg.-RH (Incl Ref. 44-45)
39. 717-0528A Worm Gear, 20T
40. 725-0157 Cable Tie
41. 738-04124A Shear Pin
42. 714-0161 Key
43. 736-0351 Flat Washer
44. 721-0179 Oil Seal
45. 741-0661A Flange Bearing
46. 618-0124 Reducer Hsg.-LH (Incl Ref. 44-45)
47. 711-04283 Auger Axle
48. 684-04107 Spiral Assembly- LH
49. 714-04040 Bow Tie Cotter Pin
50. 731-04870 Spacer
51. 741-0493A Flange Bushing
52. 736-0188 Flat Washer
53. 741-0245 Hex Flange Bearing
54. 736-0242 Bell Washer
55. 629-0071 Extension Cord
56. 746-04230 Auger Clutch Cable
57. 710-04525 Carriage Bolt, 5/16-18 x .750
58. 712-04103 Hex Nut, 5/16-18
59. 736-04216 Bell Washer, .340 x .872 x .060

Cub Cadet 528 SWE Specifications

General

Engine Type	4-cycle OHV
Engine Displacement	277cc
Clearing Width	28 inches
Intake Height	21 inches
Auger Diameter	12 inches
Speeds	6 forward / 2 reverse
Stages	Two-stage
Auger Material	Steel
Impeller Diameter	12 inches
Start Type	Recoil
Throw Distance	40 ft
Starter	Electric
Fuel Tank Capacity	5 qt
Skid Shoes	Adjustable
Warranty	3-year limited
Chute Rotation	200°
