Cub Cadet 528 SWE User Manual

27
9
Parts List
1. 710-1652 AB Screw, 1/4-20 x 0.625
2. 731-04792A Belt Cover
3. 732-0705 Cable Guide
4. 711-1268B Actuator Shaft
5. 746-04229 Drive Clutch Cable
6. 732-0209 Extension Spring
7. 790-00207 Drive Clutch Cable Guide Bracket
8. 684-04156 Shift Rod Assembly
9. 750-04474 Axle Support Tube
10. 714-0126 Hi Pro Key
11. 710-0602 TT Screw, 5/16-18 x 1.00
12. 717-04210 Gear, 56T
13. 736-0362 Flat Washer
14. 741-0245 Hex Flange Bearing
15. 790-00206 Auger Clutch Cable Guide Bracket
16. 756-0625 Cable Roller
17. 738-0924 C Screw, 1/4-28 x 0.375
18. 618-04288 Dogg Assembly - LH
— 618-04287 Dogg Assembly - RH
19. 726-04012 Push-on Nut
20. 750-04477 Spacer
21. 790-00156 Shift Bracket Spacer
22. 732-04311 Torsion Spring, .750ID x .968 Lg.
23. 731-05297 Spacer
24. 716-0104 E Ring
25. 736-0188 Flat Washer, .76 x 1.49 x .06
26. 736-0626 Flat Washer
27. 741-04076 Ball Bearing
28. 738-04180 Axle
29. 731-04873 Spacer
30. 710-0654A TT Sems Screw, 3/8-16 x 1.0
31. 710-0788 TT Screw, 1/4-20 x 1.0
32. 790-00185 Shaft Retainer - LH
33. 634-04136 Wheel Complete - LH
634-04137 Wheel Complete - RH
34. 736-0242 Bell Washer
35. 710-0627 Hex Bolt, 5/16-24 x 0.75
36. 684-04154 Friction Wheel Support Brkt. Assy.
37. 790-00096 Auger Cable Guide Bracket
38. 748-0190 Spacer
39. 738-04184 Shoulder Screw
40. 790-00226 Frame Cover
41. 656-04025 Friction Wheel Disc Assembly
42. 618-04283 Drive Shaft Assembly
43. 684-04159 Friction Wheel Assembly
— 735-04054 Friction Wheel Rubber Only
44. 716-0136 Retainer Ring
45. 726-0221 Speed Nut
46. 790-00183 Wheel Drive Frame
47. 756-04109 Auger Pulley
48. 736-0505 Flat Washer
49. 710-1245B Hex Bolt, 5/16-24 x 0.875
50. 712-04064 Flange Lock Nut, 1/4-20
51. 790-00230 Bearing Sleeve
52. 741-0919 Ball Bearing
53. 750-04571 Spacer
54. 732-04308 Torsion Spring
55. 710-04520 Hex Screw, 5/16-24 x 1.25
56. 756-04179 Pulley Half
57. 754-04088 V-Belt, 2L x 33
58. 710-0106 Hex Screw, 1/4-20 x 1.25
59. 790-00208 Drive Clutch Idler Bracket
60. 748-04097 Shoulder Spacer
61. 732-0264 Extension Spring
62. 712-0413 Jam Lock Nut, 5/8-18
63. 750-04303 Spacer
64. 756-04113 Pulley Half
65. 736-0247 Flat Washer
66. 710-0191 Hex Bolt, 3/8-24 x 1.25
67. 748-04053 Pulley Adapter
68. 746-0956A Steering Cable
69. 790-00186 Shaft Retainer - RH
70. 750-0767 Axle Spacer
71. 712-04065 Flange Lock Nut, 3/8-16
72. 754-04050 V-Belt,.500 x 35.00 Lg
73. 710-0751 Hex Screw, 1/4-20 x .620
74. 790-00217 Speed Selector Pivot Bracket
75. 790-00218 Speed Selector Shift Bracket
— 723-0608 Tire Chains (If Equipped)
To order replacement
parts, call the Customer
Dealer Referral Line at
1-877-282-8684,
or visit
www.cubcadet.com to
find the nearest Cub
Cadet service dealer in
your area.

Cub Cadet 528 SWE Specifications

General

Engine Type	4-cycle OHV
Engine Displacement	277cc
Clearing Width	28 inches
Intake Height	21 inches
Auger Diameter	12 inches
Speeds	6 forward / 2 reverse
Stages	Two-stage
Auger Material	Steel
Impeller Diameter	12 inches
Start Type	Recoil
Throw Distance	40 ft
Starter	Electric
Fuel Tank Capacity	5 qt
Skid Shoes	Adjustable
Warranty	3-year limited
Chute Rotation	200°
