55
SPECIFICATIONS
Model 8404
PTO No. or Remote control valve
ports
2 (4 optional)
PTO HP 33.4
PTO shaft SAE 1-3/8 in., 6 splines
Revolutions Mid PTO 2000 (@ 2,542 rpm)
Rear PTO 540 (@ 2,451 rpm)
Minimum turning radius (without brake) 123 in. (3,125 mm)
Traction system Swing drawbar
Weight (with ROPS) 3836 lbs.
Approx.
Speed
(@2700 rpm
w/Std. tires)
Forward Low range 1.1 - 3.4 mph (1.8 - 5.5 kph)
High range 4.8 - 15.0 mph (7.7 - 24.3 kph)
Reverse Low range 1.0 - 3.2 mph (1.6 - 5.1 kph)
High range 4.4 -13.9 mph (7.1 - 22.4 kph)
Tires Ag Front 8.0" - 16"
Rear 13.6" - 24"
Industrial Front 10" x 16.5" NHS
Rear 14.9" x 24"
