55
SPECIFICATIONS
Model 8454
PTO No. or Remote control valve
ports
2 (4 optional)
PTO HP 38.0
PTO shaft SAE 1-3/8 in., 6 splines
Revolutions Rear PTO 540 (@ 2,451 rpm)
Minimum turning radius (with brake) 112.7 in. (2,865 mm)
Traction system Swing drawbar
Weight (with ROPS) 3792 lbs.
Approx.
Speed
(@2600 rpm
w/Std. tires)
Forward
Low range 0.2 - 0.7 mph (0.4 - 1.2 kph)
Medium Range 1.1 - 3.6 mph (1.7 - 5.8 kph)
High range 4.6 - 15.3 mph (7.4 - 24.6 kph)
Reverse
Low range 0.2 - 0.6 mph (0.3 - 1.0 kph)
Medium Range 0.9 - 3.0 mph (1.4 - 4.8 kph)
High range 3.8 - 12.7 mph (6.1 - 20.4 kph)
Tires Ag Front 9.5" - 16"
Rear 14.9" - 24"
Industrial Front 12" x 16.5"
Rear 17.5" x 24"
