Cub Cadet 928 SWE

29
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 684-0102 Panel, Handle ................................ 1
2 710-0276 Screw, Carriage, 5/16-18 x 1.0 ...... 1
3 710-0458 Screw, Carriage, 5/16-18 x 1.75 .... 1
4 710-0459A Screw, Hex Cap, 3/8-24 x 1.5 GR5 1
5 710-0597 Screw, Hex Cap, 1/4-20 x 1.0 GR5 6
6 710-0599 Screw, Hx Wash Hd Tapp .............
1/4-20 x .5
4
7 710-0805 Screw, Hex Cap, 5/16-18 x 1.5 GR5 1
8 710-0895 Screw, Hx Wash Hd Tapp .............
1/4-15 x .75
2
9 711-0653 Pin, Clevis, .312 x 1.0 .................... 1
10 712-0116 Nut, Insert Jam Lk, 3/8-24 GR5 ..... 1
11 712-04063 Nut, Hx Insert Flnge Lk, 5/16-18 GrF 5
12 712-04064 Nut, Hx Insert Flnge Lk, 1/4-20 GrF 6
13 714-0104 Pin, Internal Cotter ......................... 1
14 714-0507 Pin, Cotter, 3/32 x .75 .................... 2
15 731-0846C
777S32236
Chute, Upper, 6.0 ..........................
Graphic, Danger .........................
1
1
16 731-0851A Flange Keeper, Chute ................... 3
17 731-0903D Chute, Lower ................................. 1
18 731-1313C Cable Guide, Chute Tilt ................. 2
19 732-0145 Spring, Compression ..................... 1
20 732-0193 Spring, Compression ..................... 1
21 732-0746 Spring, Torsion .............................. 1
22 735-0199A Bumper, Rubber ............................ 2
23 736-0105 Washer, Belleville, .375 x .87 x .063 1
24 736-0231 Washer, Flat, .344 x 1.125 x .12 .... 1
25 36-0506A Washer, Special, .286 x 1.25 x .06 1
26 736-0509 Washer, Flat, .35 Sq x .72 x .134 2
27 746-0902 Cable, Chute Control, 66" .............. 1
28 746-0903 Cable, Chute Control w/Clip, 66" 1
29 747-0877 Rod, Cam ...................................... 1
30 748-0362 Cam, Handle Lock ......................... 2
31 748-0363 Pawl, Handle Lock ......................... 1
32 784-5594 Bracket, Cable ............................... 1
33 784-5604 Handle, Chute Tilt .......................... 1
34 784-5619A Handle, Shift .................................. 1
35 784-5679 Bracket, Handle Support, 5/8 LH ... 1
36 784-5680 Bracket, Handle Support, 5/8 RH .. 1
37 784-5681 Bracket, Handle Support, 3/8 LH ... 1
38 784-5682 Bracket, Handle Support, 3/8 RH .. 1
NOTE: Please add the applicable color code
below to the part number to order a replace-
ment part. For instance, if a part, numbered
700-xxxx, is painted Cub Yellow, the part num-
ber to order would be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Powder Black: 0637
