Cub Cadet 98M7 User Manual

29
Ref
No.
Part Number Description
1 914-0474 Cotter Pin
2 710-1652 Screw 1/4-14 x .825
3 936-0264 Flat Washer.330 ID x.630 OD
4 914-0104 Cotter Pin
5 932-0306A Compression Spring
6 734-2010 Wheel, 9 x 2.125
7 912- 0414 Top Lock Tab Weld Nut 1/4-20
8 16855 Ratchet Pawl Plate
9 10622BP Plastic Spring Ratchet
10 748-0381 Pawl RH
948-0188B Pawl LH
11 938-0137A Shlder Screw.340 ID x.285 OD
12 948-0318 Wheel Ratchet
13 736-0270 Bell Washer.265 ID x.75 OD
14 710-0751 Hex Cap Screw 1/4-20 x.620
15 937-3000 Grease Fitting
16 736-0931 Flat Washer.203 ID x.403 OD
17 747-0924 Wheel Pin Lock
18 682-9020A-0498 Caster Assembly RH
682-9021A-0498 Caster Assembly LH
19 682-9024-0498 Caster Bracket Assembly RH
682-9026-0498 Caster Bracket Assembly LH
20 720-0223 Grip
21 732-0803A Spring Lever
22 938-0529 Shoulder Nut.825 x .165 Lg.
23 936-0369 Flat Washer .508 ID x 1.0 OD
24 782-0566B-0637 Pivot Arm Assembly
25 750-0515 Spacer .510 ID x .70 OD
26 741-0978 Slv Bearing .504 ID x .830 OD
27 950-1056 Shlder Spacer, .385ID x .715Lg
28 710-0653 Tap Screw 1/4-20 x .375
Ref
No.
Part Number Description
29 682-7528-0637 Chain Cover Assembly
30 741- 0324A Flge Bearing .506 ID x .590 Lg
31 682-7526-0637 Transmission Axle Assembly
32 918-0263A Transmission Ass’y Complete
33 734-1857 Wheel 7 x 2
34 913- 0453 Chain
35 638-0012 Rear Axle Assembly
36 941-0522 Flge Bearing .506 ID x .715 Lg
37 782-0568-0637 Height Adjustment Spring Brkt.
38 950-0151 Spacer .550 ID x .750 OD
39 710-1315 Screw 3/8-16 x .25
40 911- 0 8 35 Clevis Pin .50 Dia x 4.82 Lg.
41 750-0807 Spacer .385 ID x .624 OD
42 732-0832 Torsion Spring
43 710-0779A AB Screw, #10-16 x .500
44 731- 06874 Trail Shield
45 687-02495 Handle Bracket Assembly - LH
46 687-02494 Handle Bracket Assembly - RH
47 725-0157 Cable Tie
48 710 -1348 Screw 1/4-14 x.500
49 710-0260A Carriage Bolt 5/16-18 x.62
50 911 -114 6 Caster Axle
51 912- 0397 Wing Nut
52 712- 04063 Flange Lock Nut 5/16-18
53 726-0214 Push Cap
54 936-0232 Wave Washer.531 ID x.781 OD
55 736-0366 Flat Washer.640 ID x 1.12 OD
56 741-0685 Flange Bearing
57 731-1888 Hubcap - Spoke w/ Hole
58 731-0982C Hubcap - Radial Spoke
59 710-0604A Screw, 5/16-18 x .625
