Cub Cadet CC-1000PS

4
5
1
DETAIL C
SCALE 1 : 4
4
6
2
DETAIL D
SCALE 1 : 5
6
G
DETAIL G
SCALE 1 : 5
23
10
H
DETAIL H
SCALE 1 : 7
6
Center Spacer (23) inisde Swivel Clevis (10) on Drawbar Assembly. Insert Axle (6)
halfway into Undercarriage (2). Push Axle (6) through Swivel Clevis (10) and
Spacer (23) and then through rest of Undercarriage (2).
Attach Front Support (5) to Poly Body (1) and tighten Lock Nuts (4).
5
Assembly Instructions
4
5
