DETAIL W
SCALE 1 : 5
12
Operating Instructions
Storing Lawn Sweeper:
Empty hopper bag and thoroughly clean Lawn Sweeper before storing.
1.
Store Lawn Sweeper away from excessive heat to prevent damage.
2.
Brushes must not contact ground during storage to prevent damage.
3.
Remove quick-release pins to separate hopper bag from Lawn Sweeper.
4.
Carefully remove tension tube and collapse hopper bag for compact storage.
5.
Remove one quick-release pin from hitch, fold hitch onto cross hitch tube,
6.
and replace quick release pin.
4 5
6
