Cub Cadet CC-4624V2

10
9
6
8
7
13
14
13
DETAIL Q
SCALE 1 : 2
34
Attach Hitch Mount Tubes (6) to Sweeper Assembly and tighten hardware.
Attach Hitch Cross Tube Assembly (13) by depressing snap buttons and
insterting into Hitch Mount Tubes (34).
Install Hitch Assembly (14) using tethered quick release pins in desired
position on Hitch Cross Tube Assembly (13).
DO NOT OVERTIGHTEN.
4
Assembly Instructions
1
3
2
