10
Preparing the mower for service.
Place wheel chocks (not included) behind the back tires of the mower
and apply the parking brake on the mower.
YOU MAY NOW SERVICE THE MOWER.
Wheel Chock
STEP 10
ASSEMBLY AND OPERATING INSTRUCTIONS
STEP 9
x2
To lower the mower:
1) Before Lowering the Lift, Remove the Wheel Chocks and
Parking Brake.
IMPORTANT WHEN LOWERING
MUST USE HANDLE TO OPERATE CYLINDER
2) Pump handle twice to release pressure from
locking position.
3) Step down on the Locking Bar with your foot, at the
same time, slowly turn the cylinder release valve with the
handle counterclockwise. Only 1/2 turn is required to
release the pressure. Do not overturn the release valve.
Keep your foot on Locking Bar until it is completely
lowered or passed the last locking position.
To Next Page
