8 se c t i O n 3 — as s e M b l y & se t -up
Set-Up
Gas and Oil Fill-Up
Refer to the separate engine owner’s manual for additional
engine information.
Add oil provided before starting unit for the first time out 1.
of the box.
Service the engine with gasoline as instructed in the 2.
separate engine owner’s manual.
Use extreme care when handling
gasoline. Gasoline is extremely flammable and the
vapors are explosive. Never fuel the machine
indoors or while the engine is hot or running.
Extinguish cigarettes, cigars, pipes and other
sources of ignition.
Never fill fuel tank indoors with engine
running or until the engine has been allowed to cool
for at least two minutes after running.
Tow Bar
To attach the tow bar:
Remove the spring pin and clevis pin from the end of the 1.
tow bar receiver. See Fig. 3-3.
Insert the tow bar into the receiver.2.
Reinsert the clevis pin through aligning holes in both the 3.
tow bar and the receiver.
Fasten with the spring pin to secure. See Fig. 3-4.4.
