25
Model CSV 050
Ref
No.
Part Number Description
1 736-0314 Thrust Washer.375 ID x.70 OD
2 749 -04172 Upper Handle
3 720-0279 Knob
4 710-0599 Screw, 1/4-20 x.500
5 710-1205 Eye Bolt
6 781-1056 Upper Handle Bracket
7 710-0726 Hex Cap Screw 5/16-12 x.750
8 720-04072 Star Knob
9 710 -1174 Carriage Bolt
10 731- 0 4911 Nozzle Handle Clip
11 749-04165 Lower Handle
12 711-12 93 Studs
13 710-0703 Carriage Screw 1/4-20 x.75
14 712- 0397 Wing Nut 1/4-20
15 710-0751 Hex Cap Screw 1/4-20 x.620
16 681-0195 Hose Base Adapter Assembly
(Incl. Ref.# 17-19)
17 716-0104 E Ring.500 Dia
18 732-3035 Compression Spring
19 711-1571 Clevis Pin
20 736-3020 Flat Washer.271 ID x.630 OD
21 781-04223 Upper Flail Housing
22 681-04088 Chipper Chute Assembly
23 747-04985 Hose Cradle
24 712-04064 Flange Lock Nut, 1/4-20
25 748-0457 Spacer
26 731-2478 Hose Nozzle
27 710-3288 Hex Cap Screw 1/4-20 x 2.625
28 723-0295 Adjustment Clamp
29 749-1270A Nozzle Handle
Ref
No.
Part Number Description
30 764-0648A Vacuum Hose
31 720-0369 Handle Plug
32 731-06469 Hose Adapter
33 712- 0442 Cap Lock Nut, 1/4-20
34 710 -1611B TT Screw, 5/16-18 x .750
35 781-04082 Front Wheel Support Brace
36 781-04081 Rear Wheel Support Brace
37 681-0156A Handle Bracket Ass’y RH
681-0155A Handle Brkt Ass’y LH
38 714-0104 Cotter Pin
39 726-0299 Push Cap
40 711- 0 49 0 8 Axle
41 710-04482 HHg, 3/8-16 x .875
42 741-04242 Height Adjustment Bearing
43 687-02342 Pivot Arm Assembly
44 720-0426 Height Adjustment Knob
45 732-1026 Spring Lever
46 687-02051 Height Lever Assembly
(Incl. Ref.# 44-45)
47 736-0741 Bell Washer.760 ID x.25 OD
48 7 38 -1172 Shoulder Screw,.750 x.500
49 634-04347 Front Wheel
50 712-04065 Flange Lock Nut, 3/8-16
51 736-0232 Washer, Wave, .531 x .781 x .013
52 634-04367 Rear Wheel
53 631-04232A Engine Shroud
54 710 -04744 Screw, #12-16 x 1.00
55 741-04108 Brg. Flg, Hex
56 748-0190 Spacer
57 736-0369 Washer, Flat, .508ID x 1.00 OD
To Next Page
