27
Model CSV 050
Ref
No.
Part Number Description
1 664-0095 Bag Assembly
2 681-0154 Screen Assembly
3 710-1054 Hex Screw 5/16-24 x 1.0
4 781-0490 Chipper Blade
5 781-0735 Pin Clip
6 719-0329 Flail
7 715- 0166 Spiral Pin
8 711-14 01 Clevis Pin
9 712- 0 411 Lock Nut, 5/16-24
10 73 6 - 0119 Lock Washer, 5/16
11 681-04145 Impeller Assembly
(Incl. Ref.# 3 – 10)
12 710-1650 Shoulder Screw, #12-24 x.30 x.46
13 781-0721B Lower Flail Housing
14 712- 04063 Flange Lock Nut 5/16-18
15 710-0607 Screw, 5/16-18 x.500
16 747-04297 Hinge Pin
17 731-2293A Nozzle
18 781-1064 Base Adapter Door
19 7 32-115 6 Torsion Spring
20 726-0106 Cap Speed Nut 1/4
21 711-1551 Pivot Rod
22 731-2485A Nozzle Door Lever
23 710 -1256 Hex Screw, #8-18 x 1.25
24 750-1294 Shoulder Spacer
25 732 -3118 Extension Spring
Ref
No.
Part Number Description
26 7 32 -1151A Nozzle Door Torsion Spring
27 731-2294A Nozzle Door
28 664-04040 Bag
29 631-0083 Chute Assembly
30 710-0726 Hex Index Screw, 5/16-12 x.750
31 736-0247 Flat Washer.375 ID x 1.25 OD
32 736 -0217 Lock Washer 3/8
33 710-0818 Hex Cap Screw 3/8-24 x 2.0
34 725-170 0 Switch Cover
35 725-3166 Safety Switch
36 731-1613 Safety Switch Cover
37 710-0224 Hex Washer Screw #10-16 x.50
38 629-0920A Wire Harness
39 714-0104 Cotter Pin
40 732-0962 Compression Spring
41 781-0778A Mounting Bracket
42 747-1153 Lock Rod
43 710-3195 Hex Cap Screw 5/16-18 x 4.5
44 710-3025 Hex Cap Screw 5/16-18 x.625
45 710-0654A Hex Washer Screw 3/8-16 x 1.00
46 710-1220 Screw, #12-16 x.750
47 710-0351 Screw #10 - 16 x.500
48 736-0607 External L-Washer 5/16
49 726 -0139 Speed Nut
— 723-0400 Safety Glasses (Not Shown)
