20 se c t i O n 6 — Ma i n t e n a n c e & ad j u s t M e n t s
Cleaning the Engine Intake Screen
The engine intake screen area is located on the lower half of the
dash. It is important to keep this area free of debris. Clean this
Lubrication
WARNING!
brake, stop engine and remove key to prevent
unintended starting.
Front Wheel Axles
Each of the front wheel axles and rims is equipped with a
multipurpose lithium grease.
Steering Housing
The steering housing should be lubricated after every 25 hour of
operation. To access its lube fitting, proceed as follows:
Locate the grease fitting for the steering housing under the 2.
an equivalent No. 2 multipurpose lithium grease, through
the grease fitting.
Close the tractor hood4.
Steering Shaft
The steering shaft should be lubricated after every 25 hour of
operation. To access its lube fitting, proceed as follows:
Working beneath the left side of the tractor frame, locate the
Figure 6-5
Figure 6-6
Figure 6-7
Figure 6-4
