Cub Cadet i1050 Parts Manual

i1046 & i1050/Series i1000 SECTION HM12
11
Ref.
No.
Part No. Description
1 17840 Bracket, Transmission Mounting
2 618-04317 Hub, Wheel
3 634-04239
734-1730
934-0255
Wheel Assembly
Tire, 20 x 8 x 8
Valve, Tubeless Air
4 647-04061 Shaft Assembly, Brake Control
5 647-04094 Shaft Assembly, Hydro Control Pedal
6 683-0267C Pedal Assembly, Hydro Control
7 683-04314A Bracket, Pedal
8 710-0347 Screw, Hex Cap, 3/8-16 x 1.75 Gr5
9 710-0514 Screw, Hex Cap, 3/8-16 x 1.0 Gr5
10 710-0607 Screw, Hex Wash Hd. Tapp, 5/16-18 x .5
11 710-0726 Screw, Hex Wash Hd. Tapp, 5/16-12 x .75
12 710-0809 Screw, Hex Wash Hd. Tapp, 1/4-20 x 1.25
13 710-1266 Screw, Hex Cap, 5/16-18 x 3.5 Gr5
14 710-1325 Screw, Hex Wash Hd. Tapp, 1/4-20 x 1.625
15 710-3073 Screw, Hex Cap, 5/16-18 x 2.25 Gr5
16 710-3119 Screw, Hex Cap Lock, 3/8-16 x .75 Gr5
17 710-04484 Screw, Hex Wash Hd. Tapp, 5/16-18 x .75
18 710-04648 Screw, Hex Cap, 7/16-14 x 8.5 Gr5
19 711-04554 Spacer, .479 x .75 x 4.97
20 711-0832 Ferrule, 3/8-24 x .375 Dia.
21 712-0346 Nut, Hex Jam Insert Lock, 1/2-20 Gr5
22 712-0431 Nut, Hex Flange Top Lock, 3/8-16 GrF
23 712-3004A Nut, Hex Flange Lock, 5/16-18 Gr5
24 712-0290 Nut, Hex Lock, 7/16-14 GrA
25 712-3050 Nut, Lug, 7/16-14
26 712-04063 Nut, Hex Flange Insert Lock, 5/16-18 GrF
27 712-04065 Nut, Hex Flange Insert Lock, 3/8-16 GrF
28 712-0375 Nut, Hex Lock, 3/8-16
29 714-0104 Pin, Internal Cotter
30 714-0111 Pin, Cotter, 3/32 x 1/0
31 715-0143 Pin, Spirol, .25 x 1.25
32 726-0214 Cap, Push, 5/8
33 731-05846 Fan, Hydro
34 732-0209 Spring, Extension, .48 x 2.03
35 732-0335 Spring, Compression, .405 x 1.17
36 732-0716C Spring, Extension, .59 x 4.0
37 732-0814 Spring, Extension, .56 x 5.52
38 735-0239 Pad, Foot, 4.0 in. Lg
39 735-0662 Pad, Hydro Control Pedal
Ref.
No.
Part No. Description
40 736-3027 Washer, Flat, .531 x 1.75 x .09
41 736-0227 Washer, Flat, .39 x 1.5 x .134
42 736-0290 Washer, Flat, .625 x 1.0 x .067 HT
43 736-3010 Washer, Flat, .407 x .812 x .135 HT
44 736-3039 Washer, Flat, .406 x 1.5 x .105
45 736-3050 Washer, Flat, .406 x .812 x .051
46 736-04263 Washer, Hydro Lock
47 738-0129 Bolt, Shoulder, 3/8-16: .5 x 2.0
48 738-0143 Bolt, Shoulder, .496 x .336: 3/8-16
49 738-0155 Bolt, Shoulder, .435 x .160 : 5/16-18
50 738-0347 Spacer, Shoulder, .625 ID x .169
51 741-0225 Bearing, Hex Flange
52 741-3065B Bearing, Hex Flange, .625 ID Split
53 747-04562 Rod, Park Brake
54 747-04584A Rod, Brake
55 747-04598 Rod, Drive Engage
56 747-04629 Bracket, Brake Pedal
57 747-04649 Rod, Hydro Dump
58 748-04155 Spacer, T-Axle
59 750-04776 Spacer, .38 x .625 x .265
60 750-0555 Spacer, .254 x .5 x .39
61 750-0566A Spacer, .26 x .372 x 1.03
62 754-04134 V-Belt, 88.4
63 756-04209 Pulley, V Type Drive, 3.06
64 756-04274 Pulley, V Type, 4.5
65 756-0981B Pulley, Flat Idler, 2.75
66 783-04570A Arm, Idler
67 783-04881 Bracket, Foot Pedal Support
68 783-04981 Bracket, Park Brake
69 783-05330 Bracket, Support
70 783-05473 Bracket, Belt Keeper
71 916-04339A Transmission, Hydro RH
72 918-04342A Transmission, Hydro LH
73 17962 Plate, Switch
74 710-0224 Screw, Hex Wash Hd. Tapp, #10-16 x .5
75 710-0227 Screw, Hex Wash Hd. Tapp, #8-18 x .5
76 725-04039 Switch, Brake
77 725-1644 Switch, Reverse
78 726-0320 Plate, Insulator Nut
79 725-04374 Harness, Reverse Jumper
80 710-0599 Screw, Hex Wash. Hd. Tapp, 1/4-20 x .5
Transmission Drive & Controls
