Cub Cadet i1050 Parts Manual

i1046 & i1050/Series i1000 SECTION HM12
17
Ref.
No.
Part No. Description
1 918-0660 Spindle Assembly
2 683-0254B Bracket, Deck Hanger, LH
3 683-04278 Bracket, Idler
4 683-04335 Deck Assembly
5 710-0347 Screw, Hex Cap, 3/8-16 x 1.75 Gr5
6 710-0528 Screw, Hex Cap, 5/16-18 x 1.25 Gr5
7 710-0599 Screw, Hex Wash. Hd. Tapp, 1/4-20 x .5
8 710-1260A Screw, Hex Wash. Hd. Tapp, 5/16-18 x .75
9 710-3015 Screw, Hex Cap, 1/4-20 x .75 Gr5
10 710-3103 Screw, Hex Cap, 5/16-18 x 2.0 Gr5
11 712-0206 Nut, Hex, 1/2-13 Gr5
12 712-04063 Nut, Hex Flange Insert Lock, 5/16-18 GrF
13 712-04065 Nut, Hex Flange Insert Lock, 3/8-16 GrF
14 712-0417A Nut, Hex Flange, 5/8-18
15 712-0641 Nut, Hex, M16-1.5
16 712-3006 Nut, Hex, 1/4-20 Gr5
17 712-3010 Nut, Hex, 5/16-18 Gr5
18 712-3083 Nut, Hex Insert Lock, 1/2013
19 714-0111 Pin, Cotter, 3/32 x 1.0
20 714-0162 Pin, Cotter, 5/32 x 1.25
21 715-0108 Pin, Spring, 1/4 x 1.0
22 717-04074 Gear, Deck Adjust
23 721-04041 Adapter, Water Nozzle
24 726-0233 Nut, Push, .25 x .5
25 726-0269 Nut, Push On Speed, 3/8 Thrd.
26 731-3005 Roller, Front
27 732-0306A Spring, Compression, .531 x 1.75
28 732-0594A Spring, Extension, .91 x 7.33
29 732-0826A Spring, Extension, .865 x 4.68
30 734-04155 Wheel, Deck Ball, 5.0
31 736-0119 Washer, Lock, 5/16
32 736-0225 Washer, Internal Tooth Lock, 5/8
33 736-0247 Washer, Flat, .406 x 1.25 x .157 HT
Ref.
No.
Part No. Description
34 736-0270 Washer, Belleville, .265 x .75 x .062
35 736-0343 Washer, Flat, .33 x 1.25 x .12
36 737-04003C Nozzle, Deck Wash
37 738-04162a Spacer, Shoulder, .884 x .190
38 738-04235 Shaft, 1/2 Dia x 20.8
39 738-3056 Bolt, Shoulder, .496 x 2.5:3/8-16
40 942-04124 Blade, 3 in 1 Star, 14.88
41 942-04125 Blade, 3 in 1 Star, 16.28
42 747-1116 Rod, Deck Release
43 747-1130B Rod, Deck Front Hanger
44 750-1206 Spacer, .542 x .75 x .5
45 754-04118 V-Belt, Type A x 122.5
46 756-04129 Pulley, Idler, 4.25 Dia
47 783-0141 Skirt, Deck Center
48 783-0142 Skirt, Deck RH
49 783-05118 Bracket, Idler
50 783-05397 Bracket, Roller Height
51 783-0747B Cover, Deck Belt LH
52 783-0805C Cover, Deck Belt RH
53 710-0134 Screw, Carriage, 1/4-20 x .62 Gr2
54 712-3087 Nut, Wing, 1/4-20
55 731-05264 Plug, Mulching
56 756-1188 Pulley, Deck, 5.75 Dia
57 750-0952 Spacer, .792 x 1.06 x 1.8
58 741-0919 Bearing, Ball
59 738-1186 Shaft, Spindle, 6.05 Lg
60 737-3000 Fitting, Lube
61 619-0042A Housing, Spindle
62 17983 Shield, Bearing
63 931-1032B
703-1693A
711-0792
726-0106
732-0602A
Chute Assembly, Discharge
Bracket, Hinge Mounting
Pin, Hinge, .25 x 6.75
Nut, Push Cap Speed, 1/4
Spring, Torsion
46” Mowing Deck
