Cub Cadet i1050 Parts Manual

i1046 & i1050/Series i1000 SECTION HM12
27
Ref.
No.
Part No. Description
1 KH-24-755-141-S Kit, Rocker Cover (Incl. Ref.2 & 4pc Ref. 3)
2 KH-24-153-28-S O-Ring, Valve Cover
3 KH-M-651030-S Screw, Flnge M6 x 1.0 x 30
4 KH-32-318-01-S Kit, #1 Cylinder Head (Incl. 4pc Ref. 26 and
KH-24-841-03-S)
5 KH-12-755-03 Kit, Retainer
6 KH-12-173-01 Cap, Valve Spring
7 KH-24-089-02 Spring, Valve
8 KH-235011-S Retainer, Spring
9 KH-66-032-05-S Seal, Valve Stem
10 KH-24-017-01 Valve, Intake (Std.)
11 KH-24-016-01 Valve, Exhaust (Std.)
12 KH-32-326-04-S Kit, Breather Hose, (Incl. 1pc Ref. 13)
13 KH-25-237-14-S Clamp, Hose
14 KH-32-081-02-S Kit, Breather Housing (Incl. 15,16)
15 KH-M-547050-S Nut, Lock, M5 x 0.8
16 KH-32-468-01-S Washer, Sealing
17 KH-32-072-02-S Stud, Breather Cover
18 KH-32-019-01-S Kit, Tappet
19 KH-32-411-02-S Rod, Push
20 KH-24-841-03-S Kit, Cylinder Head Gasket (Incl. Head Mtg.
Hardware and KH-24-041-49-S and KH-24-
153-27-S
21 KH-32-318-02-S Kit, #2 Cylindre Head (Incl. 4pc Ref. 26 and
KH-24-841-03-S)
22 KH-32-186-02-S Arm, Rocker
23 KH-32-100-04-S Nut, M10 x 0.75
24 KH-32-086-03-S Screw, Set
25 KH-24-599-02-S Pivot, Rocker Arm
26 KH-12-086-16 Screw, Flange, M10 x 1.5 x 90
27 KH-32-086-04-S Screw, Flange, M6 x 1.0 x 45
28 KH-32-096-06-S Kit, Breather Valve Cover (Incl. 1pc Ref.2)
29 KH-24-445-01 Strap, Lifting
30 KH-M-645016-S Screw, Flnge Thrd. Frmng M6 x 1.0 x 16
31 KH-32-096-04-S Kit, Breather Cover (Incl. Ref. 32)
32 KH-32-041-01-S Gasket, Breather Cover
33 KH-32-050-01-S Filter, Breather
Not Illustrated
KH-24-041-49-S Gasket, Exhaust
KH-24-153-27-S O-Ring
i1046 & i1050 Cylinder Head/Valves/Breather
