i1046 & i1050/Series i1000 SECTION HM12

Ref.

No.

Part No. Description

1 KH-24-211-03-S Bolt, Carriage, M6 X 1.0 X 25

2 KH-24-090-33-S Lever, Governor

3 KH-M-641060-S Nut, Flange, M6 x 1.0

4 KH-24-089-01 Spring, Linkage

5 KH-25-158-08 Bushing, Linkage Retainer

6 KH-24-079-04 Linkage, Throttle

7 KH-25-158-11 Bushing, Throttle Linkage

8 KH-M-545016-S Screw, Flng. Thrd. Frmng, M5 x 0.8 x 16

9 KH-M-547050-S Nut, Lock, M5 x 0.8

10 KH-24-083-03 Spring, Choke Return

11 KH24-126-161-S Bracket, Control

12 KH-M-645016-S Screw, Flnge Thrd. Frmng M6 x 1.0 x 16

13 KH-47-237-02 Clamp, Dual Conduit

14 KH-24-086-43-S Screw, Torx Hd. Ctsk, M5 x 0.8 x 16

15 KH-24-079-22-S Linkage, Choke

16 KH-24-112-27-S Spacer, Control Assembly

17 KH-24-090-47-S Lever, Throttle Actuator

18 KH-24-090-13 Lever, Throttle Control

19 KH-24-468-01 Washer, Flat, 5.5mm

20 KH-M-545020-S Screw, Flng. Thrd. Frmng, M5 x 0.8 x 20

21 KH-41-468-03 Washer, Spring, 1/4

22 KH-24-090-05 Lever, Choke

23 KH-M-403025 Screw, Hex Cap, M4 x 0.7 x 25

24 KH-M-446030-S Nut, M4 x 0.7

25 KH-24-468-20-S Washer, Flat, 5mm

26 KH-24-089-55-S Spring, Governor

27 KH-24-089-18

KH-24-089-25-S

Spring, Governor, Model i1046 ONLY

Spring, Governor, Model i1050 ONLY

i1046 & i1050 Engine Controls
