Control Adjustments
To adjust the choke control, remove the air cleaner.
Move the choke control to the full choke position. The
carburetor choke should be completely closed (See
Figure 18). If not, loosen the casing clamp screw.
Move the casing, wire and engine choke lever in the
direction shown until the choke is completely closed.
Tighten the casing clamp screw and replace the air
cleaner.
Figure 18
To adjust the throttle control, remove the air cleaner.
Move the the throttle control to the “FAST” position.
The swivel should be against the throttle stop (See Fig-
ure 19). If not, loosen the casing clamp screw. Move
the casing and wire in the direction shown by the arrow
until the swivel is against the throttle stop. Tighten the
casing clamp screw and replace the air cleaner.
Figure 19
The adjustable governor control was set at the factory.
If adjustment is required, consult your Authorized Cub
Cadet Service Dealer.
WIRE AND
CASING
CASING CLAMP SCREW
CHOKE
CLOSED
THROTTLE
STOP
SWIVEL
CASING CLAMP
SCREW
