While holding the belt and pulley together, rotate the
pulley to the left (See Fig. 7-9). Continue holding and
rotating the pulley and belt until the belt is fully rolled into
To place the new belt begin by routing the belt around the 5.
two outer spindle pulleys as shown in Fig. 7-8.
Then route the belt around the two deck idler pulleys as 6.
show in Fig. 7-8.
Reinstall the belt keeper rod loosened earlier.7.
CAUTION: Failure to reinstall the belt keeper rod
system.
Remount the belt guards removed earlier.8.
Re-install the deck making sure the belt remains routed 9.
around the pulleys as instructed.
se c t i O n 7— se r v i c e
