19
Model PR-521
Ref.
No.
Part No. Description
1 647-0004 Control Handle Assembly
2 710-1205 Rope Guide
3 720-0279 Handle Knob 1/4-20 Thd.
4 710-1174 Carriage Bolt 5/16-18 x 2" Lg.
6 720-0314 Hand Knob
7 710-1270 Oval C-Sunk Mach. Scr.
9 712-0324 Hex L-Nut 1/4-20 Thd.
11 749-0705 Upper Handle
12 720-0295 Foam Grip
13 749-0928 Lower Handle
14 726-0240 Cable Tie
15 764-0310 Rear Catcher Frame
16 746-0551 Control Cable - 43”
17 731-1523 Front Cover: Black
18 764-0311 Front Catcher Frame
19 764-0635 Grass Bag
20 714-0104 Int. Cotter Pin 5/16" Dia.
21 732-0678 Door Spring - R.H.
22 732-0677 Door Spring - L.H.
23 782-7000 Rear Discharge Door
29 735-0639 Spark Plug Boot
30 732-0700 Wire Rod
31 731-1236 Rear Flap
32 753-0588 Blade Adapter (Kit includes 32-34)
33 710-1044 Hex Bolt 3/8-24 x 1.5" Lg.
34 736-0524A Blade Bell Support
36 742-0741 21" Mulching Blade
39 736-0356 Bell-Wash. .39" I.D. x 1.38"
40 712-0798 Hex Nut 3/8-16 Thd.
41 15261A Height Adj. Plate
42 15262B Pivot Bar
43 14832 Front Spring Lever Ass’y. w/Knob
44 738-0507B Shld. Bolt .5" Dia. x .357"
45 736-0105 Bell-Wash. .38" I.D. x .88" O.D.
46 738-0102 Front Axle Bolt
47 720-0190 Spring Lever Knob
48 732-0417A Rear Spring Lever
49 14578 Height Adj. Assy. Comp. - RH
N/I 14579 Height Adj. Assy. Comp. - LH
50 14765 Pivot Bar R.H.
N/I 14766 Pivot Bar L.H.
51 782-5002 Front Baffle
52 710-0654A Hex L-Wash.Scr. 3/8-16 x 1" Lg.
53 782-5003 Rear Baffle
54 710-1017 Torx Mach AB-Tap Scr. 1/4 x.62"
55 710-0896 HexIndWash. Scr. 1/4-14:.625
56 682-0516A Handle Brkt. Ass’y.—RH
57 682-0515A Handle Brkt. Ass’y.—LH
58 782-0047A Cutting Deck
59 734-2008 Wheel Black Link
62 736-0270 Bell-Washer 1/4" I.D.
63 682-7000 Hinged Mulching Plug
64 731-1409 Chute Deflector: Side Discharge
65 710-0599 Hex Hd Self-Tp Scr. 1/4-20 x .5" L.
66 782-5007A Mulching Baffle Plug
67 782-5004 Mulching Baffle - R.R.
68 751B224437 Muffler Guard
69 710-1268 Hex Washer Head Screw
71 710-0192 Truss Scr. #10-24 x .38" Lg.
72 720-0275 Knob
76 736-0504 Wave Washer
77 731-0982A Hub Cap - Rad. Spoke - Beige
79 738-0213 Rear Axle Bolt
80 750-0535 Spacer
81 710-1248 Weld Pin
82 746-0883 Control Housing w/o Lever
83 751B281440 Engine Shroud
Ref.
No.
Part No. Description
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Cub Yellow, the part number to
order would be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Powder Black: 0637
