Cub Cadet RZT L 54-KW Specifications

engIne Rzt L 42 Rzt L 46 Rzt L 50 kH Rzt L 50 kW Rzt L 54 kH Rzt L 54 kW
Engine Type
22 HP*
professional-grade
Kohler
®
7000 Series
V-Twin OHV
23 HP*
professional-grade
Kawasaki
®
FR
®
,
V-Twin OHV
23 HP*
professional-grade
Kohler 7000 Series
V-Twin OHV
23 HP**
professional-grade
Kawasaki FR,
V-Twin OHV
24 HP*
professional-grade
Kohler 7000 Series
V-Twin OHV
23 HP**
professional-grade
Kawasaki FR,
V-Twin OHV
Engine Displacement/Orientation 725cc/Vertical 726cc/Vertical 725cc/Vertical 726cc/Vertical 725cc/Vertical 726cc/Vertical
Cylinders/ Material • 2/Cast-iron sleeve •
Engine Start • Electric •
Lubrication • Full-pressure with spin-on oil filter •
dRIve SYSteM
Transmission • Dual Hydro-Gear™ EZT 2200 •
SteeRIng
Lap Bar Control • Adjustable twin levers, oversized lap bars with full-length comfort grips •
CHaSSIS
Frame • Heavy-duty 12-gauge one-piece, full-length steel frame •
Front Axle • Heavy-duty 2" x 3" fabricated axle •
Caster Wheel Pivot Bearings • Sealed ball bearing •
eLeCtRICaL SYSteM
Alternator/Charging System • 15 amp regulated •
Battery Voltage •
12 volt/230 cold crank amp •
Safety Systems • Operator presence •
OPeRatIOn
PTO Clutch • Electronic fingertip engagement •
Deck Lift • Hand lever, multi-position •
Seat • Cub Comfort™ deluxe high-back seat, 12-position fingertip adjustment mechanism with 6" seat travel •
Parking Brake • Integrated parking brake in lap bars •
Hour Meter • Standard electronic •
addItIOnaL SPeCIFICatIOnS
Forward Speed • 7 mph •
Reverse Speed • 3 mph •
Front Tires 11" x 4" – 5" (rib) 13" x 5.0" – 6" (rib) 13" x 5.0" – 6" (rib) 13" x 5.0" – 6" (rib) 13" x 5.0" – 6" (rib) 13" x 5.0" – 6" (rib)
Rear Tires 18" x 8.5" – 8" (turf) 18" x 8.5" – 8" (turf) 18" x 9.5" – 8" (turf) 18" x 9.5" – 8" (turf) 18" x 9.5" – 8" (turf) 18" x 9.5" – 8" (turf)
Turning Radius • Zero •
Fuel Tank Capacity • 2.8 gal. •
Fuel Gauge • Standard (site window in tank) •
Cup Holder w/ Utility Bin • Standard •
Rear Bumper • Standard •
Wheelbase • 43.5" •
Length/Width (w/ chute)/Height 80"/50"/36" 80"/54"/36" 80"/57"/36" 80"/57"/36" 80"/61"/36" 80"/61"/36"
Approximate Weight 480 lbs. 495 lbs. 527 lbs. 527 lbs. 610 lbs. 610 lbs.
MOWeR deCk
Cutting Width/Blades
42" twin-blade
(high-lift)
46" twin-blade
(high-lift)
50" triple-blade
(high-lift)
50" triple-blade
(high-lift)
54" triple-blade
(high-lift)
54" triple-blade
(high-lift)
Deck Cutting Height • 1.5" – 4", 8-position height adjustment •
Deck Style/Construction
Floating,
12-gauge stamped
Floating,
12-gauge stamped
Floating,
12-gauge stamped
Floating,
12-gauge stamped
Floating,
11-gauge fabricated
Floating,
11-gauge fabricated
Deck Drive System • Heavy-duty Kevlar
®
belt •
Anti Scalping/
Rear Striping Roller
2 adjustable-gauge
wheels, greasable
4 adjustable-gauge
wheels, greasable
2 adjustable-gauge
wheels, greasable
rear striping rollers
2 adjustable-gauge
wheels, greasable
rear striping rollers
4 adjustable-gauge
wheels, greasable
1 front roller
4 adjustable-gauge
wheels, greasable
1 front roller
Deck Wash • Patented SmartJet™ high-pressure deck washing system •
WaRRantY
†
• 3-year/120-hr limited warranty •
Rzt
®
L SeRIeS
zeRO-tuRn RIdeRS
This brochure is for advertisement purposes only. The product depictions are not meant to be used or relied upon as a substitute for the safety and use information that is published in the respective
operator’s
manual. Before operating the machine, read, understand and follow all instructions in the manual and on the machine. Specifications and programs are subject to change without notice.
Images may not reflect dealer inventory and/or unit specifications.
* As rated by Kohler, all power levels are rated at 3600 RPM per SAE J1940 gross. ** As rated by Kawasaki, horsepower tested in accordance with SAE J1995 and rated in accordance with
SAE J2723 and certified by SAE International † See your local Cub Cadet Independent Dealer for warranty details.
773-05485 Printed in U.S.A. 1/14 © 2014 Cub Cadet
attaCHMentS make a smart choice even smarter.
Dial up the versatility of your rider by adding attachments that let you tackle more of your outdoor chores with confidence and ease.
Twin bagger, mulch kit, weight kit, rear hitch, rear spreader, lawn sweeper, steel cart, poly cart, lawn dethatcher, lawn spike and plug
aerator, lawn roller, rear engine guard and light kit.

Cub Cadet RZT L 54-KW Specifications

General

Brand	Cub Cadet
Model	RZT L 54-KW
Category	Lawn Mower
Language	English
