Cub Cadet RZT L User Manual

Assembly & Set-Up
3
9
Contents of Crate
     
   
NOTE: 
features may vary by model. Not all features in this manual are
applicable to all tractor models and the tractor depicted may
differ from yours.
Tractor Preparation
Manually Moving the Tractor
 Engage the transmission bypass rods, one on each side of
the tractor, to move the tractor manually without starting it.
The transmission bypass rods are located on the rear of the
tractor, just inside each rear wheel. Engage the bypass rods
by pulling each one out (a) and to the right (b) to lock it into

a
b
Figure 3-1
2. Disengage the bypass rods by reversing steps a & b after

 Remove the deck wash system nozzle adapter from the
manual bag and store for future use.
Install Operator’s Seat
To install the seat proceed as follows:
NOTE: The seat is shipped with the seat switch and seat pan
attached.
 Cut any straps securing the seat assembly and the drive
control levers to the tractor. Remove any packing material.
NOTE: 
seat and the seat switch.
2. Remove the two shoulder screws and lock nuts in the seat

Wire Harness
Seat Pan
Shoulder
Screw
Lock
Nuts
Shoulder
Screw
Figure 3-2
 Rotate the seat into position and secure the seat into place
with the previously removed shoulder screws and lock


Wire Harness
Seat Bracket
Shoulder
Screws
Lock
Nuts
Figure 3-3
NOTE: 
the seat box hole before continuing.
