21
Model SC 621E
Ref.
No.
Part No. Description
Ref.
No.
Part No. Description
1. 710-1174 Carriage Bolt 5/16-18 x 2.0 31. 631-0071 Grass Bag Cover
2. 714-0104 Cotter Pin .072 x 1.12 Lg. 32. 747-0939 Pivot Rod
3. 720-0241 Knob Assembly 5/16-18 33. 726-0106 Cap Nut
4. 726-0240 Strap 4.3” Lg. 34. 747-0937 Frame (Grassbag)
5. 736-0451 Saddle Washer .320 ID x.830 OD 35. 747-0940A Support Rod
6. 720-0270 Handle Knob 1/4-20 36. 664-0076 Grass Bag
7. 736-0451 Saddle Washer 37. 710-1250 Carriage Bolt 5/16-18 x 1” Lg.
11. 712-0324 Lock Nut 1/4-20 38. 712-0267 Hex Nut 5/16-18
12. 646-0875 Control Cable Housing 39. 725-1276 Battery Pack - 12 Volt
14. 746-0912 Control Cable 44” Lg. 40. 731-0891A Battery Tray
16. 731-0904A Upper Control Housing 41. 725-0873 Ignition Switch
17. 731-0924 6-Speed Shift Lever 42. 725-0201 Ignition Key
18. 713-0397 Gear Insert 44. 725-1206 Plug
19. 710-1667 C Sunk Tap Screw #10-16x.625 45. 625-0021 Wire Harness
20. 732-0627 Shift Lever Spring 46. 710-1270 Hex Bolt 1/4-20 x 1.3” Lg.
21. 16864 6 Speed Rack Cable Brkt. 47. 736-0270 Bell Washer 1/4” I.D.
22. 731-0905A Lower Control Housing 49. 782-9012 Lower Battery Tray
23. 731-0906 Cable Mounting Cap 50. 736-0242 Bell Washer 5/16” I.D.
24. 731-0620 Control Lever 51. 710-0969 Tap Screw 1”
25. 746-0939 6 Speed Cable 52. 725-1538 Harness Ext.
26. 746-0713 Drive Cable, 52” 53. 710-0111 Screw 1/4-20 x 1.25
27. 647-0004 Control Handle 54. 712-0287 Hex Nut 1/4-20
28. 720-0294 Foam Grip (2 Req’d.) 55. 725-0727 Battery Charger
29. 749-0439B Upper Handle 56. 725-1428 Fuse Holder
30. 749-0907A Lower Handle 725-0298 Fuse 7.5 Amp (Not Shown)
