Cub Cadet SC2450 Part List Manual

Sc Series 5 Sc2450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-719517-01560 BLOCK ASSY, CYLINDER 1
4 CY-124060-01050 PLUG PT1/8 1
5 CY-105311-01090 PLUG 30 (SUS) 4
6 CY-119623-01250 PLUG 45 1
7 CY-124160-01910 PLUG PT1/4 1
8 CY-119285-01990 PLUG 25 3
9 CY-119620-02020 BOLT 8
12 CY-119717-02411 BUSH, CAMSHAFT 1
13 CY-27241-120000 PLUG 12 1
14 CY-719717-02901 MAIN BEARING SET 4
26 CY-119717-02930 BEARING, THRUST 2
29 CY-119515-01200 BOLT, CYLINDER HEAD 14
30 CY-119517-01330 GASKET, CYL.HEAD 1
31 CY-119810-02941 BEARING,THRUST Over-size 0.25 2
34 CY-719717-02911 MAIN METAL Under-size 0.25 4
FIG. 1. CYLINDER BLOCK
Copyright 2009 Cub Cadet Yanmar LLC
