23
1. 684-04106B Handle Engagement Assembly RH
2. 738-04194 Flange Shoulder Screw
3. 731-04894B Lock Plate
4. 711-04287 Pivot Rod
5. 735-0199A Rubber Bumper
6. 710-04354 Screw, 1/4-20 x.375
7. 731-04896A Clutch Lock Cam
8. 712-04081A Shoulder Nut, 1/4-20
9. 725-04314 Wire Harness (Not Shown)
10. 725-1649 Light Socket
11. 720-0274 Handle Grip
12. 710-1233 Screw, #10-24 x 0.375
13. 738-04122 Shoulder Screw, 1/4-20 x 1.345
14. 710-04586 Screw, 1/4-20 x 1.625
15. 749-04190 Upper Handle RH
16. 710-0449 Carriage Screw, 5/16-18 x 2.25
17. 720-04039 Shift Knob
18. 931-05335 Handle Panel (Includes Ref. #19)
19. 731-05324 Lens
20. 725-04213 Lamp
21. 631-04134A Handle Clutch Lock RH Assy
22. 725-0157 Cable Tie
23. 712-04064 Flange Lock Nut, 1/4-20
24. 732-0193 Compression Spring
25. 790-00203 Shift Lever
26. 790-00248 Panel Bracket
27. 738-04125 Shoulder Screw
28. 746-0605 Cable Barrel Holder
29. 746-04227A Speed Selector Cable
30. 736-0463 Flat Washer, .25 x .630 x .0515
31. 710-0224 Screw, #10-16 x .500
32. 710-0606 Hex Screw, 1/4-20 x 1.50
33. 731-04427A Upper Chute
34. 790-00155 Joystick Bracket
35. 710-04187 Hi-Lo Screw, 1/4-15 x 0.5
36. 984-04116B 4-Way Chute Control™ Assembly
37. 749-04191 Upper Handle LH
38. 710-04326 Screw, #8-16 x 0.50
39. 732-04219A Clutch Lock Spring
40. 731-04954 Steering Control
41. 738-04126 Pin, 3/16
42. 716-04036 E Ring
43. 631-04133 Handle Clutch Lock LH Assy
44. 684-04105A Handle Engagement Assembly LH
45. 784-5594 Cable Bracket
46. 720-04072 Star Knob
47. 712-04063 Flange Lock Nut, 5/16-18
48. 731-1313C Chute Tilt Cable Guide
49. 711-04469A Clevis Pin
50. 710-1260A AB Screw, 5/16-18 x 0.75
51. 749-04138 Lower Handle
52. 732-04238 Torsion Spring
53. 736-0262 Flat Washer
54. 731-04890A Joystick Pulley Cover
55. 710-0262 Carriage Bolt, 5/16-18 x 1.50
56. 710-0895 Hi-Lo Screw, 1/4-15 x .75
57. 710-04071 Carriage Bolt, 5/16-18 x 1.0
58. 731-04861A Lower Chute
59. 710-0627 Hex Screw, 5/16-24 x .750
60. 684-04162 Chute Support Bracket
61. 712-3087 Wing Nut, 1/4-20
62. 714-04040 Bow Tie Cotter Pin
63. 726-0470 Cable Tie
9
Parts List
To order replacement
parts, call the Customer
Dealer Referral Line at
1-877-282-8684
or visit
www.cubcadet.com to
find the nearest Cub
Cadet service dealer in
your area.
G
E
N
U
I
N
E
F
A
C
T
O
R
Y
P
A
R
T
S
