tank™ LZ SeRIeS
CoMMeRCIaL ZeRo-tuRn RIdeRS
engIne tank™ LZ 48 tank™ LZ 54 tank™ LZ 60
Engine Type
Commercial-grade Briggs
and Stratton
®
Commercial
Turf Series V-Twin OHV
Commercial-grade Kohler
®
Command
®
V-Twin OHV
Commercial-grade Kohler
®
Command
®
V-Twin OHV or
Kawasaki
®
FX Series V-Twin OHV
Engine Displacement/
Orientation
724cc/vertical 725cc/vertical
725cc/vertical (Kohler
®
)
852cc/vertical (Kawasaki
®
)
Engine Horsepower 24 HP* 25 HP* 27 HP*
Engine Fuel Gasoline
Lubrication/Filter Full pressure w/spin-on filter
Cooling System Air
Air Cleaner Heavy-duty cyclonic air filter Heavy-duty canister air filter Heavy-duty canister air filter
Alternator 12V–15 amp. regulated 12V–20 amp. regulated 12V–20 amp. regulated
Fuel Capacity Twin 7.5-gallon tanks (15-gal. total)
Fuel Gauge Standard (mounted on tank)
dRIve SYSteM
Drive System PARKER™ Torqpact 14cc pumps and 280cc wheel motors
Ground Speed Fwd: 11 mph/Rev: 5 mph
Hydraulic Fluid Castrol Edge w/ Syntec Power 5W- 50
Hydraulic Fluid Capacity 7 qt. total
Hydraulic Oil Filter Individual filter cartridges standard
Controls Quick-adjust lap bar system
Lap Bar Dampers Standard
Return to Neutral Standard
Braking/Parking Brake Dynamic drum, lever control
SteeRIng
Caster Wheel
Pivot Bearings
Steel bushing, greasable
Front Axle Pivoting steel axle
ChaSSIS
Frame Heavy-duty rail frame 3/8 x 5" laser cut steel w/tie-down slots
tIReS
Front Tire Size 13" x 6.5"-6" (smooth)
Rear Tire Size
24" x 9.5"– 12" (turf) 24" x 12"– 12" (turf) 24" x 12"– 12” (turf)
dIMenSIonS
Length/Width/Height 86.5" / 49.5" / 73.5" 86.5" / 55.5" / 74" 86.5" / 61.5" / 74"
Wheelbase
54"
Front Track Width 43"
Rear Track Width 50" 52" 52"
Weight (approx.) 1,110 lbs. 1,160 lbs. 1,200 lbs.
MoweR deCk
Deck Size/Type 48" sloped nose 54" sloped nose 60" sloped nose
Deck Style/System Floating
Deck Blades Triple-blade/high lift blade standard
Deck Construction 10-gauge fabricated with 7- & 10-gauge reinforcements
Deck Drive Belt – Kevlar
®
B-section
Deck Wash Patented SmartJet™ high-pressure deck washing system
Deck Lift Single pedal, spring-assisted
Deck Height Adjustment 1" – 5" (in .25" increments)
Blade Spindle
Construction
Cast-aluminum
Deck PTO Electronic fingertip engagement
Front Anti-Scalping
Wheels/Nose Roller
2 standard, greasable/1-nose roller
Rear Anti-Scalp Rollers/
Striper
Full width, adjustable
addItIonaL SPeCIFICatIonS
ROPS
Standard, foldable/2-position lock (ISO 21299, OSHA 1928)
Monitor/Hour Meter
Standard
Seat Type Two-tone Elasticity Vibration Control (EVC) comfort seat w/arm rests
Cup Holder Standard
Storage Box Standard
Rear Bumper & Hitch Heavy-duty rear bumper w/hitch standard
waRRantY
†
4-year or 2000-hour limited warranty
attaChMentS
THAT BOOST PRODUCTIVITY ALL YEAR ROUND
Whether you’re working through the heat of
summer or the dead of winter, our attachments
are made to boost your earning potential the
whole year through. So you can maximize your
profits while getting the best results possible.
POWER LIFT
LIGHT KIT
ULTRA
TRACTION
TIRE/RIM
12-VOLT
OUTLET KIT
72" SNOW
BLADE
ALSO AVAILABLE:
• MULCH KIT
• CASTER WHEEL KIT
• SEAT SUSPENSION KIT
This brochure is for advertisement purposes only. The product depictions are not
meant to be used or relied upon as a substitute for the safety and use information
that is published in the respective operator’s
manual. Before operating the
machine, read, understand and follow all instructions in the manual and on the
machine. Specifications and programs are subject to change without notice.
Images may not reflect dealer inventory and/or unit specifications.
*as rated by engine manufacturer
† See your local Cub Cadet Independent Dealer
for warranty details.
Cub Cadet commercial products are intended
for professional use.
773-05152 Printed in U.S.A. 12/12 © 2013 Cub Cadet
