5
For a proper working machine, use Factory Approved Parts. V-belts are specially designed to engage and disengage safely. A substitute (non-OEM)
V-Belt can be dangerous by not disengaging completely.
Ref. No. Part No. Description
1 17840 Transaxle Bracket Mount
2 618-04452 Transmission 4-Speed
3 710-0176 Screw, HH Cap: 5/16-18 x 2.75”
4 710-0376 Screw, HH Cap: 5/16-18 x 1.00”
5 710-04377 Screw, HH Cap: 7/16-20 x 2.75”
6 710-0513 Screw, HH Cap: 1/4-28 x .625”
7 710-0520 Screw, HH Cap: 3/8-16 x 1.50”
8 710-1878 Screw, HH Cap: 3/8-16 x 1.75”
9 710-3008 Screw, HH Cap: 5/16-18 x .75”
10 710-3015 Screw, HH Cap: 1/4-20 x .75”
11 711-1000 Belt Keeper
12 712-04063 Nut, Flange Lock: 5/16-18
13 712-04064 Nut, Flange Lock: 1/4-20
14 712-04065 Nut, Flange Lock: 3/8-16
15 712-0700 Nut, Flange: 9/16-18
16 714-0145 Hairpin Clip: 092” x 1.64” Long
17 718-0758A Pulley Hub
18 720-0142 Grip
19 731-05766 Trailing Shield
20 732-04409 Extension Spring
21 732-04443 Extension Spring
22 736-0105 Washer, Spring: .401” x .870” x .063”
23 736-0322 Washer, Flat: 450” x 1.250” x .164”
24 736-0329 Washer, Lock: 1/4”
25 736-04256 Washer, Flat: .39” x .87” x .06”
26 738-04166 Spacer, Shoulder: .50” x .1475”
27 747-04635 Belt Keeper Rod
28 747-04673 Loop Link Coupling
29 747-04678 Trans Mount Rod
30 754-04145 Belt, V Type, Drive
31 756-04129 Idler Pulley: 4.25” Dia.
32 756-04258 Flat Sheave 7.75”
33 756-04260 Engine Pulley 3.20” x 4.35” Dia.
34 756-04280 Idler Pulley 3.50” Dia.
35 787-01469 Shift Rod, Lower
Ref. No. Part No. Description
36 787-01470 Shift Rod, Upper
37 787-01473 Belt Keeper
38 787-01523 Wheel Drive idler Bracket
39 618-04438 Drive Spindle Assembly
40 618-04439 Spacer Spindle Assembly
41 731-05938 Mulch Plug
42 687-02251 Idler Arm Assembly
43 687-02254 Deck Assembly 33-inch
44 710-0451 Bolt, Carriage: 5/16-18 x .75”
45 710-0514 Screw, HH Cap: 3/8-16 x 1.00”
46 710-3106A Screw, Carriage: 3/8-16 x 1.75”
47 710-1260A Screw, LD: 5/16-18 x .750”
48 710-3184 Screw, HH Cap: 3/8-16 x 2.00”
49 631-04244 Chute Deflector Assembly
50 712-0417A Nut, Flange: 5/8-18
51 712-0641 Nut, Hex
52 712-3017 Nut, Hex 3/8-16
53 732-04406 Extension Spring: Timing Belt Tension
54 732-04452 Extension Spring: Deck Brake
55 736-0760 Washer, Lock
56 738-0347 Spacer, Shoulder: .625” x .169”
57 738-04162A Spacer, Shoulder: .884” x .190”
58 742-04154 Blade: 17.9”
59 754-04136 Belt, Blade Timing
60 754-04139 Belt, V Type, Deck Engagement
61 756-04129 Idler Pulley 4.25”
62 756-04280 Idler Pulley 3.50”
63 756-0616 Idler Pulley V-Type 5.0”
64 787-01440 Idler Timing Bracket
65 721-04041 Water Nozzle Adapter
66 737-04003C Water Nozzle
67 634-04349 Wheel 16 x 4 x 8
68 736-0242 Washer, Bell: .340” x .872” x .060”
69 710-0627 Screw, HH Cap: 5/16-24 x .75”
70 710-1315 Screw, TT: 3/8-16 x 1.25”
71 710-1236 Screw, Carriage: 5/16-18 x 1.00”
12AE764
