Insert #5 poles into the #8 connectors and connect with the #6 connector. Tighten
screws. Repeat on the other side. Do a final tighten of all screws.
Center your mattress #21 (full, 8-10" thick) on slats #22. Orient the #11 canopy on the
frame. The blue dots should be on the top of the long sides. The Velcro skirt at the
bottom. Wrap top horizontal end sleeve around the pole and secure it with the zipper.
Zip the top sleeve across both curved poles. Zip the corner sleeves around the
four vertical poles. Unzipping and Stretching the doors can make this easier. Tighten
the bottom straps under the slats. Secure the bottom skirt to the frame with the
Velcro. If door zippers are hard to close, adjust bottom velcro to make it easier.
5
6
5
8
6
11
8
21
Push Poles
all the way into
connectors
To Next Page
