Cudy POE150 User Manual

Power Socket
Ethernet Device
(switch, router, etc.)
1 2 3 4 5
Wireless AP Smart VoIP
IP Camera
PoE Injector
Powered Device (PD)
DATA
IN
P+DATA
OUT
Hardware Connection
1
P+DATA
OUT
DATA
IN
Data/PoE
DATA
IN
P+DATA
OUT
AC Socket
Physical Appearance
2
Data/PoE
Green
Red
PoE injector got 100-240V power input
The terminal equipment connected to
P+DATA port is powered
AC Socket
DATA
IN
P+DATA
OUT
Connect with AC cable
Connect to the Ethernet device with cable to
transmit data.
Connect to the PD device with UTP cable to
supply power.
LED and Interface Explanation
3

Cudy POE150 Specifications

General

Brand	Cudy
Model	POE150
Category	Media Converter
Language	English
