ASSEMBLY INSTRUCTIONS
9
STEP 3
-----------------------------------------------------------------------------------
• Lower the Grill Body onto the Leg Assembly as shown, aligning the brackets between the two as shown.
• Secure Grill Body using Grill Body Connector Pin (D) and Cotter Pin (E).
STEP 4
-----------------------------------------------------------------------------------
• Attach Side Table Assembly (11) to Grill body using 4 M5x12 Screws (A). Repeat for opposite side.
D
E
A
11
