Cuisinart CPT-200 - Step 7: Install Frame Support Beams

6
ASSEMBLY INSTRUCTIONS
STEP 5
--------------------------------------------------------------------------------------
• Remove 1 screw from either end of the frame support beam B (6).
STEP 6
--------------------------------------------------------------------------------------
• Remove 1 screw from either end of the frame support beam A (9).
6
9
STEP 7
--------------------------------------------------------------------------------------
• Insert the frame support beam B in to the bottom holes of the right legs and replace the screws.
• Then position the frame support beam A between the frame support beam B and the wheel axle and
replace the screws.
Note: Do not tighten
screws in this step fully
until frame support beam A
is in place.
!
