Cuisinart CPT-200 - Step 8: Mount Wheels; Step 9: Fit Wheel Caps

F
x 2
10
10
D
x 4
7
ASSEMBLY INSTRUCTIONS
STEP 8
--------------------------------------------------------------------------------------
• Add one D washer to either end of the wheel axle then place the wheels (10) on. Add an additional D
washer to the outside of each wheel and secure using 1 F nut on either side. Tighten with a wrench.
STEP 9
--------------------------------------------------------------------------------------
• Add the wheel caps (17) to the wheels by lining up the pegs on the wheel caps with the holes on the
wheels. Press in rmly to attach.
17
17
