18 PNEG-308 Purafire
4. Dimensions
Figure 4A
Dimension
Model
C80M C225
A 20-1/2" 27"
B 13" 20"
C 21-3/4" 28"
D 5-1/8" 7-5/8"
E 3/4" 1"
F 4-1/2" 7-3/4"
G 6" 5-1/2"
