26 PNEG-308 Purafire
8. Installation
Figure 8B
This heater must be installed in accordance with local codes or in the absence to local codes, in
accordance with the National Electrical Code, ANSI/NFPA 70-1993.
NOTE: The gas supply piping must be properly sized for rated capacities. Refer to Pages 49-50 for
instructions and examples of pipe sizing.
NOTE: The gas piping must not be used to support the heater. If the installation subjects the heater to
movement or vibration, a flexible gas connector may be required. When copper tubing is used
for conveying natural gas, the tubing must be internally tinned or equivalently treated to resist
sulfur corrosion.
Figure 8C
Do not use an open flame for leak detection.
