Cumberland C80M - Page 33

11. Parts List
PNEG-308 Purafire 33
C225 NG/LP Galv Purafire 120V-60 Hz
Ref # Part # Description
1 5430-1-914 Outer Wrap
2 5430-1-109 Base Panel
2
41-0211 Modulation Base Panel
3 5430-1-901 Scroll Assembly
4 20-5111 Blower Inlet Ring
5 20-5110 Blower Wheel
6 5530-1-106 Motor Mounting Plate
7 20-5099 Motor 1/3 HP, 120V/60 Hz
8 5430-0-902 Motor Assembly
9 5420-1-123 Air Proving Switch Bracket
10 20-6016 Air Proving Switch
11 20-5098 Main Cast Burner
12 20-5020 LP Orifice (#18 Hole)
12
20-5019 NG Orifice (19/64" Hole)
12
20-5020M LP Orifice (#18 Hole) Modulation
12
20-5019M NG Orifice (11/32" Hole) Modulation
13 20-5095 Orifice Elbow
14 20-5112 3/8" x 5-5/8" Blk Nipple
14 20-5112M 3/8" x 4-1/4" Blk Nipple
15 5430-0-905 LP Gas Valve/Orifice Assembly
15 5434-0-905 NG Gas Valve/Orifice Assembly
16 20-5025 LP Main Gas Valve
16
20-5026 NG Main Gas Valve
17 5420-1-128 Gas Valve Cover
18 5430-0-909 Firebox Assembly
19 5430-1-904 Air Proving Switch Assembly
20 20-5047M 24 Volt Ignitor (all models) Metal
21 20-5045 Flame Probe
26 20-5033 Latch
27 20-5007 Plastic Bushing
28 20-5036 Transformer 120V/24V
29 20-5001 Flame Safeguard Relay
30 20-5038 Terminal Block (4 Post)
31 5420-1-125 Capacitor Bracket
32 20-5037 Capacitor 7.5 MFD/370V
33 20-5060 Toggle Switch
34 20-5061 Plastic Bushing
35 20-5032 Strain Relief Bushing
36 20-5052 18/3" x 10' Cordset
37 20-5049 1/4"-20 x 2-5/8" Eye Bolt
40 20-5065 1/2" x 1/2" Gas Ball Valve
41 20-5430-1 Wiring Harness
42 20-505-5 LED Lens Assembly
43 20-5006 J-Type #8 Speed Nut
44 20-5015 #6 x 0.25" Tubular Spacer
45 20-5012 0.25" x 0.188" Tubular Spacer
46 20-5154 0.25" x 0.938" Tubular Spacer
47 20-5066 LP Modulation Valve
47
20-5067 NG Modulation Valve
48 41-9020 NG Metal Ignitor Bracket
