11. Parts List
PNEG-308 Purafire 39
C80M X1 NG/LP Galv Purafire 220V-50/60 Hz
Ref # Part # Description
1 5420-1-914 Outer Wrap
2 5420-1-108 Base Panel
3 5420-0-901 Scroll Assembly
4 20-5005 Blower Inlet Ring
5 20-5008 Blower Wheel
6 5420-1-107 Motor Mounting Plate
7 20-5009X C80M Motor 0.11 HP, 220V, 50 Hz
8 5420-2-902 Motor Assembly
9 5420-1-123 Air Proving Switch Bracket
10 20-6016 Air Proving Switch
11 20-5010 Main Cast Burner
12 20-5137 LP Orifice (#38 Hole)
12
20-5136 NG Orifice (#14 Hole)
13 20-5022 Orifice Elbow
14 20-5028 LP Modulating Valve
14
20-5029 NG Modulating Valve
15 5424-0-905 LP Gas Valve/Orifice Assembly
15
5425-0-905 NG Gas Valve/Orifice Assembly
16 20-5025 LP Main Gas Valve
16
20-5026 NG Main Gas Valve
17 5420-1-128 Gas Valve Cover
18 5420-0-909 Firebox Assembly
19 5420-1-904 Air Proving Switch Assembly
20 20-5047M 24 Volt Ignitor (all models) Metal
21 20-5045 Flame Probe
22 20-5046 High-Limit Switch
23 20-5044 Door Hinge Rod
24 5420-1-913 Door Assembly
25 5420-2-910 Control Enclosure Assembly
26 20-5033 Latch
27 20-5007 Plastic Bushing
28 20-5036X Transformer 220V/24V
29 20-5001 Flame Safeguard Relay
30 20-5038 Terminal Block (4 Post)
31 5420-1-125 Capacitor Bracket
32 20-6007 Capacitor 5.0 MFD/370V
33 20-5060 Toggle Switch
34 20-5061 Plastic Bushing
35 20-5032 Strain Relief Bushing
36 20-5052 18/3" x 10' Cordset
37 20-5049 1/4"-20 x 2-5/8" Eye Bolt
40 20-5065 1/2" x 1/2" Gas Ball Valve
41 20-5430-1 Wiring Harness
42 20-505-5 LED Lens Assembly
43 20-5006 J-Type #8 Speed Nut
44 20-5015 #6 x 0.25" Tubular Spacer
45 20-5012 0.25" x 0.188" Tubular Spacer
46 20-5058 0.25" x 0.75" Tubular Spacer
