WARNING
Whenusingasteamcleaner,wearsafetyglassesor
afaceshield,aswellasprotectiveclothing.Hot
steamcancauseseriouspersonalinjury.
CAUTION
Cleanallfittingsbeforedisassembly.Dirtor
contaminantscandamagethefuelsystem.
Before servicing any fuel system components, (such as
fuel lines, fuel pump, injectors, etc.) which would expose
the fuel system or internal engine component to potential
contaminants prior to disassembly, clean the fittings,
mounting hardware, and the area around the component
to be removed. Dirt or contaminants can be introduced
into the fuel system and engine if the surrounding areas
are not cleaned, resulting in damage to the fuel system
and engine.
• Clean the engine. Refer to Procedure 000-009 in
Section 0. (/qs3/pubsys2/xml/en/procedures/99/99-
000-009.html) Refer to Procedure 204-008 in
Section i. (/qs3/pubsys2/xml/en/procedures/99/99-
204-008.html)
• Use electrical contact cleaner, Part Number
3824510, or equivalent, to thoroughly clean all fuel
lines before removal from the engine. Clean the
connector fittings to remove as much debris as
possible. It is very important that extra care is taken
to keep the fuel connections clean during removal
and installation. Refer to Procedure 204-008 in
Section i. (/qs3/pubsys2/xml/en/procedures/99/99-
204-008.html)
• Make sure that debris, water, steam, or cleaning
solution does not get inside the fuel system.
WARNING
