HORIZONTAL BLINDS DIAGRAM
HEADER
MANUAL TWIST
WAND
OR CORDED TILT
LIFTING CORD
SLATS
NOTE: Some blinds use a corded tilt mechanism to tilt the slats instead of a wand.
If your horizontal blinds have a corded tilt mechanism, you will need to convert it
to a wand tilt mechanism using the horizontal tilt gear. Instructions for converting
to a wand tilt mechanism can be found on page 9.
TILT GEAR
STEM
VALANCE
Vertical BLINDS DIAGRAM
SLATS
HEADER
MANUAL TWIST WAND
NOTE: The E-Wand is not compatible with vertical blinds that use a rope or chain
to open and close the slats.
TILT GEAR
STEM
SLAT
ATTACHMENT
