Current MP410 - Panel Diagram; Front Panel; Rear Panel

2 pages

To Previous Page

(c)CURRENT,INC.

H.ICHIHASHI

PANEL DIAGRAM

MP410 HEADPHONE DISTRIBUTOR

MAY 98

MP410-D

482

302.6

CURRENT

MP410 MUTI HEADPHONE AMP

MAINS

010

HP LEVEL

HEADPHONES MONITOR

345678910

MAINS:100VAC 50/60Hz

DISCONNECT INPUT POWER BEFORE REPLACING FUSE

FUSE

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

MODEL:MP410 SN_______

100VAC 50/60Hz, MAX25W

FUSE=250V 1A, IEC127 5x20mm

MADE IN JAPAN

CURRENT,INC.

PUSHPUSH

INPUT_L

THRU_L

INPUT_R

THRU_R
