GB-11
Control Panel Overview
STRONG NORMAL ECONOMY RINSE RAPID
SOAK
1 2 3 4 5 6
O N
O FF
START
RESET
PROG
1
2
3
4
5
6
1
1. On/Off Button
• To turn the dishwasher on and off.
Power On Light
• Illuminates when On/Off button is pressed.
2. Washing Cycle Indicator
• Illuminates when different washing cycle (pre-wash, main wash, rinse and drying) of the selected
programme is in progress.
Pre-wash
Main wash
Rinse
Drying
3.
Rinse Aid Refill Warning Light
• Illuminates when the rinse aid dispenser needs refilling.
Salt Refill Warning Light
• Illuminates when the salt reservoir needs refilling.
4. Programme Control Dial
• Turn the dial to select your required washing programme.
5. Start/Reset Button
• To start or reset the dishwasher.
2 3 4 5
CDW60W10_IB_110324.indd 11 24/03/2011 10:27 AM
