8. Place the door back on. Ensure the door
is aligned horizontally and vertically
so that the seals are closed on all sides
before finally tightening the top hinge.
9. Insert the hinge bracket and screw it to
the top of the unit.
10. Use a spanner to tighten it if necessary.
11. Put the hinge cover and the screw cover
back.
12. With the door closed, check that the
door is aligned horizontally and vertically
and that the seals are closed on all sides
before finally tightening the bottom
hinge. Re-adjust the levelling feet as
needed.
7. Re-fit the bracket, fitting the bottom
hinge pin. Replace both levelling feet.
Screw
10
