ILLUSTRATED PARTS LIST IP49
TP2, ILLUSTRATED PARTS/RECOMMENDED PARTS 092019D
ITEM # PART # DESCRIPTION
1 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
2 WC-61509 COVER, TOP TP2S
3A WC-820WDR
1,2
VALVE, DUMP RIGHT 120V 12W
3B WC-854
3
VALVE, BREW DUMP RIGHT 240V 12W GEM12D/
TP/TPC
4A WC-2977K
a
KIT, SPRAYHEAD FITTING METAL
4B WC-2977-101K
b
KIT, SPRAYHEAD FITTING PLASTIC
5 WC-3417-P
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
6A WC-442
1,2
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
6B WC-446
3
SOLENOID, LOCK BREW CONE RIGHT 220V
THERMOPRO/GEMTS
7A WC-844-101
1,2
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
7B WC-844-102
3
VALVE, BY-PASS, 240V NON-ADJUSTABLE W/
RESTRICTOR (WC-2945)
8A WC-723
1,2
CONTROL MODULE, UCM 120V TP2S/TP2T
GEMSS/GEMTS
8B WC-728
3
CONTROL MODULE, UCM 220V TP2S/TP2T/
GEMSS/GEMTS
9A WC-39417
LABEL, UCM PANEL 1-BATCH OPTION TP2S
CURTIS
9B WC-39416
LABEL, UCM OVERLAY SINGLE 2-BATCH
OPTION THERMOPRO CURTIS
9C WC-39444 LABEL, UCM OVERLAY 3-BATCH TP2S CURTIS
10 WC-8559
RELAY, SOLID STATE 280V/40A W/ HEATSINK
AND QUICK DISCONNECTS
11 WC-58037-101 COVER, CENTER WRAP TP 90 DEG
12 WC-596K
3
KIT, NOISE FILTER EMI 250V/30A 1PH
13 WC-1825 FAUCET, ASSY HOT WATER TP2S
14 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE
15A WC-3528
1,2
LEG, 4" ADJUSTABLE 3/8-16 THRD ITALIAN
STYLE
15B WC-3500T
3
LEG, 4” ADJUSTABLE W/TIE DOWNS 3/8-16
THRD
16A WC-13286
1,2
HARNESS, ASSY COMPLETE TP2S (INCLUDES
TERMINAL BLOCK)
16B WC-13286-104
3
HARNESS ASSY, TP2S30 (INCLUDES TERMINAL
BLOCK)
ITEM # PART # DESCRIPTION
1 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
3A WC-820WDR VALVE, DUMP RIGHT 120V 12W
6A WC-442
SOLENOID, LOCK BREW CONE RIGHT/LEFT
120V TP2T/TP2S/GEMSS/GEM
7A WC-844-101
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
8A WC-723
CONTROL MODULE, UCM 120V TP2S/TP2T
GEMSS/GEMTS
TP2S - Recommended Parts to Stock
ITEM # PART # DESCRIPTION
17 WC-2402P-P ELBOW, 3/8”FL x 3/8” NPT PLATED
18 WC-1501 FUSE, HOLDER ASSY W/5A FUSE
19A WC-37132
KIT, VALVE REPAIR FOR INVENSYS WC-
820WDR,WC-821WDR, WC-844WDR (OLDER
UNITS)
19B WC-37132-101
KIT, VALVE REPAIR FOR DELTROL
WC-820WDR,WC-821WDR, WC-844WDR
(NEWER UNITS)
20 WC-103
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
21A WC-847
1,2
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
21B WC-883
3
VALVE, INLET 2 GPM 240V 6W
22 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
23A WC-1200
2
CORD, 14/3 SJTO 6’ BLK W/PLUG
23B WC-1250
3
CORD, 4mm² 90ºC 49A 450/750V 6 FT LG W/
FERRULES ONE END
24 WC-5231 COMPOUND, HEAT SINK 5OZ
25 WC-314 POWER BLOCK, 5 STATION
26 WC-29044-101 SLEEVE, OVERFLOW ASSY
27 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
28A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
28B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
29A WC-4213-P
a
NUT, 5/8 LOCK PLATED
29B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
30 WC-4412 SCREW, 10-32x3/16” PH PN HD MS SS
31 WC-4616
SCREW, 1/4-20 x 1/2 PHILLIPS PAN HEAD
STAINLESS STEEL
32 WC-4426 SCREW, 8-32x3/8 PH HEAD TRUSS
33 WC-1805
SEAT CUP, “S” FAUCET USE ON WC-1800/B/
LB/D/DL/L/WC-1803
ITEM # PART # DESCRIPTION
14 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE
21A WC-847
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
22 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
TP2S - Main Chassis - Parts List
1
TP2S10,
2
TP2S63,
3
TP2S30
a
8QLWVEXLOWDQGODWHU6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWKROGHUXQLWV
b
Units built before 05/15/17.
