CYBEX 11000 User Manual

Cybex Eagle 11000 Chest Press Owner’s Manual
Service
Page 6-4
1 5 08014 PULLEY ASSEMBLY - 4.50 2 1 11000-002 CABLE 3 1 11000-003 CABLE 4 1 11000-200 FRAME 5 1 11000-201 WEIGHT FRAME 6 1 11000-202 PIVOT, LH 7 1 11000-203 PIVOT, RH 8 1 11000-204 SEAT BACK 9 1 11000-205 SEAT BOTTOM 10 1 11000-206 SEAT BOTTOM LINK 11 1 11000-207 REAR SEAT LINK 12 1 11000-208 FRONT SEAT LINK 13 1 11000-209 DETENT HANDLE 14 1 11000-210 ARM LH 15 1 11000-211 ARM RH 16 1 11000-212 FLOATING PULLEY 17 1 11000-213 PULLEY SHAFT 18 2 11000-303 SPRING, TORSION 19 2 11000-365 SHAFT, SECONDARY PIVOT 20 1 11000-366 SHAFT, CROSS 21 1 11000-376 THREADED STOP 22 2 11000-384 BLOCK, STOP 23 2 11000-389 ENDCAP, BEARING HOUSING 24 4 11000-390 VINYL CAP 25 2 11000-392 STOP PLATE 26 1 11000-610 -X* PLACARD, EAGLE CHEST PRESS 27 1 11000-999-X* OWNER’S MANUAL 28 1 11040-301 CLAMP BLOCK INSERT 29 2 11040-401 WT ROD .625 X 47.50 30 2 11040-409 MOLDED BUMPER PAD 31 1 11040-440 KNOB 32 2 11040-750 EXT INC WT CHANNEL 33 2 11040-754 EXTRUDED GUARD 34 2 11040-751 EXT INC WT CHANNEL 35 1 11040-770 COVER, TOP 36 1 11040-768 COVER, TOP 37 2 11040-776 CHASSIS 38 2 11040-777 TRAY, BOTTOM 39 1 11040-760 PANEL, SHROUD BACK 40 2 11040-762 PANEL, SHROUD FRONT 41 2 11040-560 DECAL, WEIGHT PLATE (10 - 290) 42 1 11050-205 LINK 43 8 11050-375 PIVOT PIN 44 2 11050-409 PLASTIC SPACER 45 1 11090-314 P/PIN,DETENT 46 2 11090-370 SHAFT, PIVOT 47 2 11090-376 RING, HANDLE GRIP 48 1 11090-385 GRIP 49 5 11090-392 FOOT COVER 50 1 3900-441 DECAL, CYBEX INTERNATIONAL 51 1 4605-381-X* WARNING LABEL 52 5 4000Y316-X* DECAL, CAUTION 53 2 4520-362-X* DECAL, CAUTION 54 2 4605-550 PLUG .250-20 SMALL 55 1 4628-312 P/PIN,DETENT 56 1 51198 WARRANTY BOOKLET (NOT SHOWN)
ITEM QTY PART NO. DESCRIPTION
57 1 8650-204 P/CAM BOLT 58 4 BR030214 RETAINING RING, .625 DIA 59 2 BS070201 COM SPRING .56 x .66 1.50 LG 60 1 CM000211 DECAL, PATENT PENDING 61 2 EZ000006 GAS SPRING 250N 62 10 FB030232 BEARING, RADIAL 17 mm EXTEN RACE 63 2 FB050211 BRG FLG .38 X .50 .25 LG 64 16 FB130207 BRG FLG 17mm X 19mm X 25mm 65 100” GB000202 BELT .95 WIDE 66 2 GP000209 PULLEY ASSEMBLY-3.50 67 7 HC700417 BHSCS .375-16 X 1.00 68 1 HC700428 BHSCS .375-16 X 2.25 69 1 HC700430 BHSCS .375-16 X 2.50 70 1 HD303312 S BOLT .250 X .500 .190-10-24 71 4 HF449063 INSERT 3/4 X 1/4-20 72 10 HF540200 GROMMET, NYLON 73 5 HN575100 LOCKNUT .190-No 10-24 74 4 HN-60065 NUT, HEX SELF- LOCKING .312-18 BLK ZINC 75 21 HN704901 LOCKNUT, .375-16 NYLON 76 1 HP286819 SPIRAL PIN .188 X 1.12 77 28 HS347600 WASHER, SAE .375 78 2 HS407100 WASHER, SPRING .650 ID x .790 OD x .062 THK 79 4 HT102214 PHIL, HEX, WASHER HD, TYPE 23, 10-24 80 18 HT542514 PN HD PHIL SC # 8 X .625 BLK 81 4 HX-60184 BALL STUD, .312 - 18 UNC x 10 mm 82 2 HY740000 SET SCREW 83 4 JC620415 BHSCS .250-20 X .75 84 26 JC700412 BHSCS .375-16 X .50 85 10 JC700420 BHSCS .375-16 X 1.25 86 2 JC700422 BHSCS .375-16 X 1.50 87 4 JC700424 BHSCS .375-16 X 1.75 88 3 PN149101 CLAMP, HOSE, SNAP GRIP 89 3 PP080207 INSERT, PLASTIC .437 DIA 11 GA 90 2 PP080226 INSERT, DOMED PLASTIC 2.00, RIB 91 2 PR060003 BUMPER, RECESS 92 2 PR060005 BUMPER, WEIGHT 93 2 4605-502 GRIP 1.38 OD X .94 ID 94 3 PU060201 BUMPER 95 45.38 PR250203 STRIP, FOAM .12 X .25 X ROLL 96 2 11000-394 DECAL, INDICATOR 97 1 11000-396 DECAL, SEAT ADJUSTING 98 1 11000-397 DECAL, SEAT ADJUSTING 99 4 JS347400 LOCKWASHER, INT TOOTH .375 100 1 HN664900 NUT, HEX SELF-LOCKING .312-18 ZINC 101 1 HS760100 SPRING RETAINING WASHER 102 1 JD343320 S BOLT .375 X 1.25 .312-18 103 4 11090-403 CAM SHEILD 104 4 HC572814 SHCS .190-10-24 X .625 105 1 11040-789 EAGLE PLAQUE 106 1 11020-334 SHIM, STOP BLOCK (up to 3 per side may be used) 107 4 HT572512 TAP SC NO. 10-24 X .50 PN HD PHIL 108 1 4800-172 SEAT PAD
ITEM QTY PART NO. DESCRIPTION
*Language Key 1-German 2-French 3-Spanish English 6-Japanese 7-Swedish 8-Russian
