Cybex Arc Trainer 750A/750AT Owner’s Manual
24
Hold the four BHSCS .375-16 x 2.25 (#13) with a 7/32” Allen wrench (#15) while tightening with a 5.
9/16” open end wrench to secure console.
Using a 7/32” Allen wrench, tighten the four BHSCS (#14d) to secure the handle assembly. Refer 6.
to the above diagram.
Pull rubber sleeves up to cover handle-to-frame connections.7.
Attach 750AT console assembly.
Locate the console assembly (#2a), four .375-16 nylon locknuts (#12) and four 1. BHSCS
.375-16 x 2.25 (#13).
Heart Rate
Display Cable
Upper Display
Cable
Contact Heart
Rate Cable
Lower Display
Cable
#2a
#13
#12
Cable
Strap
Heart Rate
Board
750AT
Locate the upper display cable and plug into the lower display cable. Refer to the above diagram.2.
Locate the heart rate display cable and plug into heart rate board. Refer to the above diagram.3.
Locate the contact heart rate cable and plug into the heart rate board. Tighten cable strap. Refer 4.
to the above diagram.
Insert (from underneath) the four 5. BHSCS.375-16x2.25(#13). Hand thread the four .375-16 nylon
locknuts (#12) in position. Refer to the above diagram
Conrm that no cables are pinched while lowering the console.6.
Hold the four BHSCS .375-16 x 2.25 (#13) with a 7/32” Allen wrench (#15) while tightening with a 7.
9/16” open-end wrench to secure console. Refer to above diagram.
To Next Page
