Assembly
Page 4-1
Product Number 8800/8810 Owner’s Manual
4 - Assembly
NOTE: Two people will be required to perform this procedure.
NOTE: It is the responsibility of the facility owner/owner of the equipment to ensure that there is
appropriate clearance around each machine to allow for safe use and passage.
NOTE: Refer to Chapter 6 for reference diagrams.
1. Read and understand all instructions thoroughly before assembling this product.
2. Verify the appropriate confi guration was received:
Correct color of machine.A.
Proper weight stack and weight stack decals. B.
Appropriate owner’s manual.C.
Warranty sheet.D.
Verify which machine was received 8800 (Chin-Up Bar Installed) or 8810 (With Chin-Up Bar).E.
3. Move to desired location.
NOTE: If machine is an 8800 and does not fi t through doorway proceed to step 10.
NOTE: If machine is an 8810 and does not fi t through doorway proceed to step 10J- 10P. Proceed to
step 13 to install Chin-Up Bar.
NOTE: If machine is an 8810 install Chin-Up Bar. Proceed to step 13 to install Chin-Up Bar.
4. Remove shipping pallet.
WARNING: Use extreme caution when removing shipping pallet.
Failure to do so could result in injury.
With an assistant, using a 9/16” wrench, carefully remove each lag bolt securing frame to A.
pallet.
Carefully place frame on fl oor.B.
7/32” Allen wrench•
3/4” Socket•
Hammer•
3/16” Pin punch•
9/16” Wrench•
Loctite #242•
Tools Required
To Next Page
