CYBEX 8800 Owner's And Service Manual

Product Number 8800/8810 Owner’s Manual
Service
Page 6-4
1 4 02106 HALF WEIGHT PEG
2 1 02203 STRAIGHT HANDLE ASSEMBLY
3 1 08007 WASHER, NYLON .515 ID x 1.000
OD x .062 THK
4 3 08229 PIN,DETENT
5 6 11040-440 KNOB
6 1 12040-357 PIN, DETENT
7 1 12060-347 PIVOT PIN
8 2 12090-322 FOOT PAD
9 4 12210-347 GUIDE ROD CAP
10 4 12210-348 GUIDE ROD CAP
11 2 13000-353 FOOT PAD
12 1 13000-354 FOOT PAD
13 1 13000-355 FOOT PAD
14 4 13000-364 BEARING, FLANGE .62 ID. x
.92 OD. x 1.75 LG
15 2 16080-312 DETENT PIN
16 2 3900-434 DECAL, CYBEX
17 2 3900-438 DECAL, CYBEX
18 18 4400-354 PULLEY
19 8 4400-355 PULLEY
20 1 4505-331 BUMPER, 1.50 DIA
21 2 4605-512 INSERT PLASTIC, 7.94
22 2 4800-263 C TOP WT 17-3X12
23 2 4800-700 GRIP, 4.75 FOAM
24 1 51122 ANKLE STRAP
25 1 51198 WARRANTY BOOK (NOT SHOWN)
26 2 8800-002 CABLE S/A LEFT SIDE
27 2 8800-003 CABLE S/A RIGHT SIDE
28 1 8800-009 LAT BAR ASSEMBLY
29 2 8800-007 HANDLE ASSEMBLY
30 2 8800-008 HANDLE ASSEMBLY
31 2 8800-100 EDGE TRIM ASSEMBLY
32 1 8800-200 FRAME
33 1 8800-202 ADJUSTING HANDLE RH
34 1 8800-203 WEIGHT FRAME RH
35 1 8800-205 ADJUSTING HANDLE LH
36 2 8800-206 PULLEY MOUNT
37 1 8800-207 DETENT POST LH
38 1 8800-208 CUSHION POST
39 1 8800-209 ARM
40 1 8800-212 WEIGHT FRAME LH
41 2 8800-215 PIVOT
42 2 8800-216 PULLEY SWIVEL
43 2 8800-218 CAM BOLT
44 1 8800-223 RACK
45 1 8800-224 DETENT POST RH
46 2 8800-333 FORMED WEIGHT CHANNEL
47 2 8800-335 COUNTERWEIGHT
48 4 8800-339 U-BUMPER
49 4 8800-343 WT ROD .625 DIA X 69.38
50 2 8800-350 FORMED GUIDE
51 2 8800-353 MOLDED TOP CAP
52 1 8800-388 DETENT PLATE
53 2 8800-444 WEAR BLOCK
54 1 8800-433 HANDLE, ROPE
55 2 BH030207 PIN, WEIGHT SELECTOR
56 4 BR030206 RING, RETAINING
57 4 BR030220 RETAINING RING 1.250 INTERNAL
58 2 BR030223 EXTERNAL RETAINING RING,
25 MM
59 6 BS070201 COM SPRING .56 x .66 1.50 LG
60 4 BS070208 COMPRESSION SPRING
61 1 CM000211 DECAL, PATENT PENDING
62 4 FB030255 BEARING RADIAL 25MM
ITEM QTY PART NO. DESCRIPTION
63 4 FB050226 BEARING,FLANGE 1.000 ID x 1.25 OD
x 1.00 LG
64 2 FB130212 BUSHING, FLANGE .75 ID x .875
OD x .75 LG
65 4 FC030010 TOLERANCE RING 1.457 ID
66 2 GQ000206 SNAP LINK
67 4 HC620431 BHSCS .250-20 X 2.00
68 20 HC700417 BHSCS .375-16 X 1.00
69 4 HF700000 PANEL FASTNER, .375-16 , U TYPE
70 N/A HM580410 BHSCS .190 10-32 X .375
REMOVED 3/19/2010
71 6 HN625200 LOCKNUT, .250-20 NYLON
72 4 HN704000 HEX NUT .375-16
73 6 HN704400 NUT, HEX JAM .375-16
74 42 HN704901 LOCKNUT, .375-16 NYLON
75 2 HP286819 SPIRAL PIN .188 X 1.12
76 4 HS308300 SPLIT LOCKWASHER .250
77 2 HS347600 WASHER, SAE .375
78 2 HS347700 WASHER, USS .375
79 4 HS720004 WASHER, FELT .641 ID X 1.250
OD X .125T
80 6 HT512517 TAP SC 10-24 X 1.00 TYPE WB
PN HD PHIL BLK
81 2 HW-60159 WASHER, SHIM
82 2 HX-60074 RING, SNAP, EXTERNAL
83 4 HT552511 SREW,TAP 8-16 X.38
84 6 JC620415 BHSCS .250-20 X .75
85 3 JC700412 BHSCS .375-16 X .50
86 8 JC700420 BHSCS .375-16 X 1.25
87 24 JC700424 BHSCS .375-16 X 1.75
88 1 JC702812 SHCS .375-16 X .50
89 2 JS347400 LOCKWASHER, INT TOOTH .375
90 4 PN660200 INSERT, PLASTIC 1.00 DIA-11 GA
91 N/A PP040004 BALL STOP REMOVED 3/19/2010
92 4 PR060005 BUMPER, WEIGHT
93 4 PR069400 BUMPER, RECESS
94 2 PU060201 BUMPER
95 2 PW-60615 PULLEY, CABLE, 2.00 OD x 1.0 HUB
96 6 8500-025-X* DECAL, CAUTION
97 1 8800-442-X* DECAL, CAUTION
98 1 4800-404 CUSHION SET/W WEAR COVER
99 1 4605-381-X* DECAL, WARNING
100 20 HT552511 TAP SC 8-16X.38 BLK
101 1 8800-351-9 FRONT PANEL (RIGHT SIDE)
102 1 8800-352-9 BACK PANEL (RIGHT SIDE)
103 1 8800-599-X* PLACARD
104 1 8800-598-X* PLACARD
105 1 8800-382-9 BACK PANEL (LEFT SIDE)
106 1 8800-380-9 FRONT PANEL (LEFT SIDE)
107 1 8800-230 CROSS TUBE
108 2 4605-522 GRIP
109 4 4605-550 PLUG .250-20
110 2 PP130003 INSERT, PLASTIC
111 1 8810-101 BAR, CHIN UP ASSEMBLY
112 2 4605-514 GRIP
113 1 4800-407 WEAR COVER
114 2 JC782817 SHCS .500-13 X 1.00 BRT ZINC
115 2 PP080230 PLASTIC INSERT
116 1 8800-228 CHIN-UP BAR
117 8 HF449063 INSERT, .75 X .250-20
118 1 8800-458 PIVOT DECAL RIGHT HAND
119 1 8800-459 PIVOT DECAL LEFT HAND
NS 2 4800-557 DECAL WT-PLATE (10-150)
NS 2 13000-551 DECAL WT-PLATE (160-200)
NS 1 8800-999-X* OPERATOR MANUAL
120 1 11040-790 DECAL, MADE IN USA
ITEM QTY PART NO. DESCRIPTION
